5V op amp

High bandwidth (20 MHz), low offset (200 µV), dual 5V op amp


Ideal for low-side current measurements, the TSV772 is a dual 20 MHz-bandwidth unity-gain-stable amplifier with a rail-to-rail input stage and slew rate of 13 V/µs.

Due to its excellent accuracy provided by a maximum input voltage of 200 µV, the TSV772 accurately amplifies small-amplitude input signals. Able to operate from a 2.0 to 5.5 V single supply, it is fully characterized for an output capacitor of 47 pF for easy usage as an ADC input buffer.

Key features

  • Gain bandwidth product: 20 MHz
  • Rail-to-rail input and output
  • Low input offset voltage: 50 µV( typ.), 200 µV (max.)
  • Low input bias current: 2 pA (typ.)
  • Low noise: 7 nV/√Hz
  • Slew rate: 13 V/µs
  • Wide supply voltage range: 2.0 to 5.5 V
  • Extended temperature range: -40 to +125°C

Application examples

high bandwidth low-side and high-side current sensing High bandwidth low-side and high-side current sensing
photodiode amplifiers Photodiode amplifiers
a/d converters input buffers A/D converters input buffers
power management in solar powered systems Power management in solar powered systems
automotive Automotive high bandwidth signal conditioning
active filters Active filters
