VND9016AJ - 具有电流检测模拟反馈功能的双通道高侧驱动器,适用于汽车应用

Smart switch with state-of-the-art embedded control functions and a new protection mechanism for several load types and power ratings

Housed in a PowerSSO-16 package, the VND9016AJ is designed for extreme low-voltage operation for deep cold cranking applications (compliant with LV124, revision 2013). This AEC-Q100 qualified device, with very low standby current, is compatible with 3V and 5V CMOS outputs.

The device integrates advanced protective functions such as load current limitation, overload active management by power limitation and overtemperature shutdown with configurable latch-off.


Key features of VND9016AJ

  • Advanced protection features:
    • Undervoltage shutdown
    • Overvoltage clamp
    • Load current limitation
    • Self limiting of fast thermal transients
    • Configurable latch-off on overtemperature or power limitation with dedicated fault reset pin
    • Loss of ground and loss of VCC
    • Reverse battery through self turn-on
    • Electrostatic discharge protection
  • AEC-Q100 qualified
  • Extreme low voltage operation for deep cold cranking applications (compliant with LV124, revision 2013)
  • Very low standby current
  • Extended current sense precision

Application examples

Power distribution
Light modules (halogen bulbs, HIDs, LEDs)
Body Control Modules (BCM)
Protected supply (ADAS)
Heating systems

Recommended resources


TwisterSIM: dynamic electro-thermal simulator for VIPower devices

A unique electro-thermal simulator that shortens the design cycle by enabling complex engineering evaluation. TwisterSIM includes an interactive selector for finding the suitable HSDs in few clicks based on load compatibility; fault condition impact analysis; diagnostic behavior analysis dynamic thermal performance, and more.

EV-VND9016AJ board: an easy way to connect VND9016AJ into the existing system
Evaluation board

The EV-VND9016AJ evaluation board provides an easy way to connect the VND9016AJ dual-channel high-side driver into an existing system. This ready-to-use board enables designers to directly connect the load, power supply and microcontroller without any additional effort for external component design and connection.
