On-demand Webinar | 3.6 kW SiC MOSFET bridgeless totem pole PFC with SCR inrush current limiter

Reference design board for a compact, 3.6 kW turnkey power factor corrector...


Designing smaller and lighter AC-DC power converters with higher input power factor (PF) and lower harmonic distortion THD is a major challenge for developers who are often pressured by time and budget constraints.

We show how you can significantly cut time-to-market by implementing an effective and efficient totem pole PFC solution with highly responsive digital inrush current control, using SiC MOSFETs and SCRs.


This on-demand webinar demonstrates how our STEVAL-DPSTPFC1 reference board with turnkey bridgeless totem pole boost circuitry can help you meet and exceed today’s efficiency and performance requirements for an AC-DC power factor corrector up to 3.6 kW. This digitally controlled bridgeless totem pole PFC with inrush current limitation delivers 97.5% full system peak efficiency and CISPR 5022 EMI compliance in a robust (4 kV surge voltage tolerance) and compact design based on SCR thyristors, SiC MOSFET, isolated drivers and the STM32 microcontroller.


Main applications:

  • High power switched-mode power supplies (SMPS)
  • EV charging stations
  • Motor drives

This webinar will guide you through:

  • Target applications and markets
  • STEVAL-DPSPFC-1 solution overview
  • Totem pole topology operation
  • Inrush current limitation with SCR
  • STEVAL-DPSPFC-1 reference design performance
  • Key power products:
    • SiC MOSFET
    • Isolated Gate Drivers STGAP
    • SCR
    • Auxiliary SMPS – Viper family
The recording includes the Q&A session, when our expert answered various interesting questions from the audience. We think may be of interest to you.



ST将保留您的浏览记录,并使用您以前访问、购买或下载过的产品和服务的详细信息,为您提供ST认为您也会感兴趣的其他产品和服务建议。
ST使用您直接提供的个人数据以及您在ST网站上的活动,并根据隐私政策向您发送(直接或通过ST分公司或分销商)有关ST产品和服务的电子报、广告或其他特定和有针对性的营销材料。您的个人资料将提供给位于欧盟和欧盟以外国家的ST分公司和分销商。您可以在我们网站的隐私政策中查阅ST分公司和分销商的列表。为了向您发送特定且有针对性的营销材料,我们会基于您直接向ST和/或通过您在ST网站上的活动提供的信息,或ST在其他情况下从您获得的其他信息进行综合分析(例如,如果您与ST、其分公司或分销商建立业务关系)。

   Speaker:

Ales Loidl
 heads the Power & Energy Application Lab in Prague, covering auxiliary power supplies ranging from a few watts to tens of kilowatts for solar and fast EV chargers. Ales has accumulated more than 17 years’ experience and has registered several patents, and today is focusing on components and applications based on wide-bandgap SiC and GaN materials.
