X-CUBE-SPN15

批量生产
Design Win

STM32Cube的双路有刷DC电机驱动器软件扩展

获取软件 下载数据摘要

产品概述

描述

The X-CUBE-SPN15 is an expansion software package for STM32Cube. The software runs on the STM32 Nucleo providing management of STSPIN840 to control dual brush DC motors. The expansion is built on STM32Cube software technology to ease portability across different STM32 microcontrollers.

It is compatible with the NUCLEO-F401RE, NUCLEO-F334R8 or NUCLEO-F030R8 development boards connected to an X-NUCLEO-IHM15A1 expansion board.

The software comes with a sample implementation driving two bidirectional dual brush DC motors.

  • 所有功能

    • Driver layer for the full management of the STSPIN840 dual brush DC motor driver
    • Sample implementation to control up to two bidirectional brush DC motors, available on NUCLEO-F401RE, NUCLEO-F334R8 or NUCLEO-F030R8 when connected to an X-NUCLEO-IHM15A1 expansion board
    • Easy portability across different MCU families, thanks to STM32Cube
    • Free, user-friendly license terms
