IIS3DWB10IS: advanced vibration sensor for next-gen predictive maintenance

Turn vibration data into faster, smarter maintenance decisions

In smart manufacturing and industrial Internet of Things (IoT), real-time, high-fidelity vibration monitoring is essential for predictive maintenance and operational efficiency. New MEMS vibration sensing technologies now deliver piezoelectric-like performance with ultrawide bandwidth, high dynamic range, and ultralow noise. These technologies also add digital edge-computing capabilities for simpler and more cost-effective designs. ST’s IIS3DWB10IS combines high-precision sensing with ISPU 2.0 and hardware accelerators, enabling real-time AI processing and advanced analytics directly at the edge. This capability allows customers to make faster decisions, reduce system complexity, and lower maintenance costs.

High-performance sensor with in-sensor AI capability

The IIS3DWB10IS captures vibration data with high clarity, enabling earlier detection of issues and faster decision-making. Its ultrawide bandwidth and high-resolution sensing support reliable monitoring of a wide range of machine behaviors, while ISPU 2.0 brings real-time edge processing directly on the device.

Learn more

Download datasheet

Key applications

Vibration monitoring

Enable early detection of mechanical anomalies with precise vibration sensing to ensure reliable condition monitoring and predictive maintenance.

High-end shock sensor

Capture fast, high-impact events with high-resolution sensing and ultrawide bandwidth for accurate shock detection and analysis.

Robotics

Support advanced robotic systems with real-time motion data to improve stability, responsiveness, and operational reliability.

Compare the IIS3DWB10IS with other vibration sensors

	IIS3DWB10IS	Competitor MEMS / Piezo
Sensing	3-axis Digital-output With bandwidth >> 10 kHz and flat frequency response Ultra low noise (<50µg/√Hz ) High dynamic range (full scale up to 200g)	1-axis Analog output Not flat frequency response Typically, lower dynamic range
Edge processing	Embedded ISPU 2.0 for real time calculation of complex features or AI algorithms and to adapt sensor configuration to the exact context	No embedded features nor processing
Integration, ease of use, cost effectiveness	Cost & BOM reduction: monolithic 3-axis digital sensor with ISPU eliminates external components, lowering BOM and system costs. Simplified design: integrated processing and a compact 4.5 x 4.5 mm² package streamline electrical and mechanical design	System complexity: it requires external conditioning, digital conversion, and calibration, increasing cost Design rigidity: single-axis sensing and lack of embedded processing hinder integration and flexible partitioning
Software libraries	Libraries for key features in vibration monitoring: fast Fourier transform (FFT), filtering, envelope detection, velocity severity, anomaly detection	n/a (there is no embedded processing)
Power consumption	Intrinsically low-power sensor, enabled by ISPU. It provides flexibility and low-power operation at system level	It requires external conversion, increasing power consumption. Microcontroller-led processing limits system-level optimization
Reliable operation	Reliable operation in a wide temperature range up to 125°C and under stressful mechanical conditions	Operation often limited to 85°C. High sensitivity to temperature variations and mechanical shocks
