40 V and 100 V N-channel STripFET F8 Power MOSFETs
AEC-Q101 qualified
Automotive 40 V and 100 V N-channel STripFET F8 Power MOSFETs
Automotive 40 V and 100 V N-channel STripFET F8 Power MOSFETs
Featuring an enhanced trench gate structure, the automotive STripFET F8 products ensure a state-of-art figure of merit for very low on-state resistance while reducing internal capacitances and gate charge for faster, more efficient switching. Cutting both on-resistance and switching losses while optimizing body-diode properties, STripFET F8 technology saves energy and ensures low noise in power conversion, motor control and power distribution circuits.
The STL305N4F8AG opens the market on automotive 40 V standard-level STripFET F8 MOSFETs.
48 V mild hybrid systems
Automotive motor control
Heating system
Braking systems
Why choose the Automotive STripFET F8 MOSFETs?
The STripFET F8 series is engineered to cater to a variety of automotive application requirements with its adaptable voltage options and customized feature levels. It provides:
- 40 V option: perfect for lower voltage automotive applications demanding high efficiency and a compact design.
- 100 V option: suitable for higher voltage automotive applications where durability and reliability are crucial.
Furthermore, the series provides both standard-level and logic-level driving capability
High current capability
Increased SOA ruggedness
Low electromagnetic noise
Compliance to automotive EMC standards
Reliability and robustness
Enhanced performance under harsh operating conditions
Flexible voltage choices
Address applications with different supply voltages
Explore the latest 40 V standard-level STripFET F8 MOSFETs
STL305N4F8AG: automotive N-channel 40 V in a PowerFLAT (5 x 6 mm) package
STL305N4F8AG: automotive N-channel 40 V in a PowerFLAT (5 x 6 mm) package
- High reliability for automotive use
- Exceeds AEC-Q101 standards
- High efficiency and power density
- Low switching losses, fast times
- Space-saving, excellent thermal performance
- Wettable flank package
Recommended resources
Automotive STripFET F8 devices
Automotive STripFET F8 devices
ST’s low-voltage MOSFETs reduce both on-resistance and switching loss while optimizing body-diode properties for very low noise during switching
