MAC and signature

The message authentication code (MAC) and the signature add authentication to integrity by encrypting the message hash. The difference between MAC and signature is that the MAC generation uses a symmetric key algorithm (Figure 19 MAC generation with secrete key algorithm), while the signature uses the message sender private key (Figure 20 Signature generation with public key algorithm).

The signature adds non-repudiation dimension to authentication:
  • A private key is not supposed to be revoked (its lifetime goes beyond the transfer operation), while a secret key may have a limited lifetime (limited to this transfer).
  • The private key used for signature is never shared, its security is higher than a secrete key.
Figure 19. MAC generation with secrete key algorithm
Figure 20. Signature generation with public key algorithm

Certificate

A certificate is related to public key algorithms. It authenticates the public key in an asymmetric transfer. It is used to counteract usurpation by an attacker that substitutes the right public key by his own key. A certificate consists in the public key signed by a certificate authority (CA) private key. This CA is considered as fully trusted.

In addition to the public key, the certificate also contains version numbers, validity period and some IDs.
