RTC periodic wakeup unit

RTC periodic wakeup unit

The STM32 MCUs provide several low-power modes to reduce the power consumption. The RTC features a periodic timebase and a wakeup unit that is able to wake up the system from low-power modes. This unit is a programmable down-counting auto-reload timer. When this counter reaches zero, a flag and an interrupt (if enabled) are generated.

The wakeup unit has the following features:
  • Programmable down-counting auto-reload timer
  • Specific flag and interrupt capable of waking up the device from low-power modes
  • Wakeup alternate function output that can be routed to the RTC_ALARM output for RTC2 and the TAMPALRM output for RTC3 (unique pad for alarm A, alarm B or wakeup events) with configurable polarity
  • Full set of prescalers to select the desired waiting period

Program the auto-wakeup unit

The table below describes the steps required to configure the auto-wakeup unit.

Table 11. Steps to configure the auto-wakeup unit
StepWhatHowComment
1Disable write protection on RTC registers. Write 0xCA and then 0x53 into RTC_WPR.The RTC registers can be modified.
2Disable the wakeup timer.Clear WUTE bit in RTC_CR.-
3Ensure access to wakeup auto-reload counter and WUCKSEL[2:0] are allowed.Poll WUTWF until it is set in RTC_ISR (RTC2)/RTC_ICSR (RTC3)
  • For RTC2: It takes around two RTCCLK clock cycles due to clock synchronization.
  • For RTC31:
    • If WUCKSEL[2] = 0, WUTWF is set. It takes around 1 ck_wut + 1 RTCCLK cycles after WUTE is cleared.
    • If WUCKSEL[2] = 1, WUTWF is set. It takes up to 1 ck_apre + 1 RTCCLK cycles after WUTE is cleared.
4Program the value into the wakeup timer.Set WUT[15:0] in RTC_WUTR.

For RTC3, the user must also program WUTOCLR[15:0]2in RTC_WUCR

See Maximum and minimum RTC wakeup period.
5Select the desired clock source.Program WUCKSEL[2:0] in RTC_CR.
6Re-enable the wakeup timer.Set WUTE in RTC_CR.The wakeup timer restarts counting down.
7Enable write protection on RTC registers.Write 0xFF into the RTC_WPR.The RTC registers cannot be modified.
1 ck_wut is the wakeup timer clock input, and ck_spre the clock output by the RTC synchronous prescaler (usually 1 Hz).
2 WUTOCLR bits are only available on RTC3 type. They are used to choose if the WUTF flag is cleared by software (WUTOCLR = 0x0000) or automatically cleared by hardware when the auto-reload down counter reaches WUTOCLR value (0x0000 < WUTOCLR ≤ WUT). For RTC2 type, WUTF must always be cleared by software.

Maximum and minimum RTC wakeup period

The wakeup unit clock is configured through WUCKSEL[2:0] in RTC_CR. Three different configurations are possible:
Periodic timebase/wakeup configuration for clock configuration 1

The figure below shows the prescaler connection to the timebase/wakeup unit and the table below gives the timebase/wakeup clock resolutions corresponding to configuration 1.

The prescaler depends on the wakeup clock selection as follows:
  • WUCKSEL[2:0] =000: RTCCLK/16 clock selected
  • WUCKSEL[2:0] =001: RTCCLK/8 clock selected
  • WUCKSEL[2:0] =010: RTCCLK/4 clock selected
  • WUCKSEL[2:0] =011: RTCCLK/2 clock selected
Figure 6. Prescalers connected to the timebase/wakeup unit for configuration 1
Table 12. Timebase/wakeup unit period resolution with clock configuration 1
Clock sourceWakeup period resolution
WUCKSEL[2:0] = 000 (div16)WUCKSEL[2:0] = 011 (div2)
LSE = 32 768 Hz488.28 µs61.035 µs
When RTCCLK= 32768 Hz, the minimum timebase/wakeup resolution is 61.035 µs, and the maximum resolution is 488.28 µs. As a result:
  • The minimum timebase/wakeup period is (0x0001 + 1) x 61.035 µs = 122.07 µs.

    The timebase/wakeup timer counter WUT[15:0] cannot be set to 0x0000 with WUCKSEL[2:0] = 011 (fRTCCLK/2) because this configuration is prohibited. Refer to the product reference manuals for more details.

  • The maximum timebase/wakeup period is (0xFFFF+ 1) x 488.28 µs = 32 s.
Periodic timebase/wakeup configuration for clock configuration 2
The figure below shows the prescaler connection to the timebase/wakeup unit corresponding to configuration 2 and 3.
Figure 7. Prescalers connected to the wakeup unit for configurations 2 and 3
If ck_spre (synchronous prescaler output clock) is adjusted to 1 Hz, then:
  • The minimum timebase/wakeup period is (0x0000 + 1) x 1 s = 1 s.
  • The maximum timebase/wakeup period is (0xFFFF+ 1) x 1 s = 65536 s (18 hours).
Periodic timebase/wakeup configuration for clock configuration 3

For this configuration, the resolution is the same as for configuration 2. However, the timebase/wakeup counter down counts starting from 0x1FFFF to 0x00000 (instead of 0xFFFF to 0x0000 for configuration 2).

If ck_spre is adjusted to 1 Hz, then:
  • The minimum timebase/wakeup period is (0x10000 + 1) x 1 s = 65537 s (18 hours + 1 s).
  • The maximum timebase/wakeup period is (0x1FFFF+ 1) x 1 s = 131072 s (36 hours).
Note:

In binary or mixed modes, ck_spre is replaced by the clock used to update the calendar (as defined by BCDU bits in RTC_ICSR). See Binary and mixed modes (RTC3 only) for more details on BCDU).

Summary of timebase/wakeup period extrema
When RTCCLK= 32768 Hz and ck_spre (synchronous prescaler output clock) is adjusted to 1 Hz, the minimum and maximum period values are listed in the table below.
Table 13. Min. and max. timebase/wakeup period when RTCCLK= 32768
ConfigurationMinimum periodMaximum period
1122.07 µs32 s
21 s18 hours
318 hours +1 s36 hours

Wakeup firmware examples

The RTC comes with a set of example projects so that the user can quickly become familiar with this peripheral. Refer to the X-CUBE-RTC Expansion Package for a complete projects list.

For example, the user can find the following projects concerning wakeup:
  • For the NUCLEO-L412RB-P equipped with an RTC3:

    STM32Cube_FW_L4_Vx.y.z\Projects\NUCLEO-L412RB-P\Examples_LL\RTC\RTC_ExitStandbyWithWakeUpTimer

  • For the NUCLEO-G071RB equipped with an RTC3:

    STM32Cube_FW_G0_Vx.y.z\Projects\NUCLEO-G071RB\Examples_LL\RTC\RTC_ExitStandbyWithWakeUpTimer_Init

  • For the NUCLEO-G431RB equipped with an RTC3:

    STM32Cube_FW_G4_Vx.y.z\Projects\NUCLEO-G431RB\Examples_LL\RTC\RTC_ProgrammingTheWakeUpTime

If one example is not available in the X-CUBE-RTC for a given STM32 MCU, the user can adapt it.
