STM32Cube MCU Package for STM32F4 series (HAL, Low-Layer APIs and CMSIS (CORE, DSP, RTOS), USB, TCP/IP, File system, RTOS, Graphic - coming with examples running on ST boards: STM32 Nucleo, Discovery kits and Evaluation boards)

STMCube is an STMicroelectronics original initiative to make developers' lives easier by reducing development effort, time and cost. STM32Cube is the implementation of STMCube that covers the whole STM32 portfolio.

STM32Cube includes STM32CubeMX, a graphical software configuration tool that allows the generation of C initialization code using graphical wizards.

It also comprises the STM32CubeF4 MCU Package composed of the STM32Cube hardware abstraction layer (HAL) and the low-layer (LL) APIs, plus a consistent set of middleware components (RTOS, USB, FAT file system, Graphics and TCP/IP). All embedded software utilities are delivered with a full set of examples running on STMicroelectronics boards.

The STM32Cube HAL is an STM32 embedded software layer that ensures maximized portability across the STM32 portfolio, while the LL APIs make up a fast, light-weight, expert-oriented layer which is closer to the hardware than the HAL. HAL and LL APIs can be used simultaneously with a few restrictions.

Both the HAL and LL APIs are production-ready and have been developed in compliance with MISRA C®:2004 guidelines with some documented exceptions (reports available on demand) and ISO/TS 16949. Furthermore, ST-specific validation processes add a deeper-level qualification.

STM32CubeF4 gathers in one single package all the generic embedded software components required to develop an application on STM32F4 microcontrollers. Following STM32Cube initiative, this set of components is highly portable, not only within STM32F4 Series but also to other STM32 Series. In addition, the low-layer APIs provide an alternative, high-performance, low-footprint solution to the STM32CubeF4 HAL at the cost of portability and simplicity.

HAL and LL APIs are available under open-source BSD license for user convenience.

Key Features

  • Consistent and complete embedded software offer that frees the user from dependency issues
  • Maximized portability between all STM32 Series supported by STM32Cube
  • Hundreds of examples for easy understanding
  • High quality HAL and low-layer API drivers using CodeSonar® static analysis tool
  • STM32F4-dedicated middleware including USB Host and Device, and TCP/IP
  • Free user-friendly license terms
  • Update mechanism that can be enabled by the user to be notified of new releases

画像

×

リソース

技術文書

製品スペック
Description バージョン サイズ
DB2164 DB2164: STM32Cube MCU Package for STM32F4 Series with HAL, low-layer drivers and dedicated middleware 5.0 150 KB
アプリケーションノート
Description バージョン サイズ
AN4323 AN4323: Getting started with STemWin Library 5.0 1 MB
AN4739 AN4739: STM32Cube firmware examples for STM32F4 Series 4.0 496 KB
ユーザマニュアル
Description バージョン サイズ
UM1725 UM1725: Description of STM32F4 HAL and LL drivers 5.0 34 MB
UM1721 UM1721: Developing Applications on STM32Cube with FatFs 2.5 516 KB
UM1722 UM1722: Developing Applications on STM32Cube with RTOS 2.5 710 KB
UM1713 UM1713: Developing applications on STM32Cube with LwIP TCP/IP stack 4.1 940 KB
UM1730 UM1730: Getting started with STM32CubeF4 MCU Package for STM32F4 Series 13.0 560 KB
UM1709 UM1709: STM32Cube Ethernet IAP example 3.1 775 KB
UM2372 UM2372: STM32Cube PDM2PCM software library for the STM32F4/F7/H7 Series 1.0 421 KB
UM1723 UM1723: STM32Cube PolarSSL example 2.1 643 KB
UM1734 UM1734: STM32Cube USB device library 3.4 1 MB
UM1720 UM1720: STM32Cube USB host library 3.1 606 KB
UM1743 UM1743: STM32CubeF4 demonstration platform 5.0 6 MB

プレゼンテーション & トレーニング資料

プレゼンテーション
Description バージョン サイズ
STM32 Embedded Software overview 2.5 342 KB
STM32 and STM8 embedded software solutions 6.0 2 MB
STM32Cube High Quality Process - Qualified STM32Cube Embedded Software libraries 1.1.0 291 KB

Publications and Collaterals

フライヤー
Description バージョン サイズ
STM32Cube eases STM32 development 17.8 577 KB
STM32F401/10/11/12/13 - High-performance Access lines 17.5 689 KB
パンフレット
Description バージョン サイズ
STM32 32-bit MCU family - Leading supplier of Arm® Cortex®-M microcontrollers 17.3 1 MB

法務

ライセンス契約
Description バージョン サイズ
SLA0048 SLA0048: Mix Ultimate Liberty+OSS+3rd-party V1 - SOFTWARE LICENSE AGREEMENT 4.13 87 KB

ツール & ソフトウェア

開発ツール・ハードウェア
Software Development Tools
ソフトウェア製品
MCUs Embedded Software
ST25 - NFC / RFID Software

ソフトウェア入手

製品型番 General Description Software Version Supplier Marketing Status ダウンロード
STM32CubeF4 - 1.23.0 ST Active
