予知保全とは?

予知保全(PdM)では、広範なセンサから収集されたデータに基づいて、潜在的な障害を発生前に見つけられる統計モデルを構築します。この手法に利用できるさまざまなツールは、しばしばクラウド上に存在しています。ツールには、例えば設備の正常性の傾向を追跡する統計分析や機械学習などがあります。

産業予知保全

状態監視とは?

状態監視(CM)とは、潜在的な障害を見つけるために、振動や温度といったさまざまなパラメータを監視することです。この手法を用いて問題を明らかにすることで、予防保全の予定を立て、故障の発生を防げるようになります。

継続的に状態監視を行うという手法は、通常、コンプレッサやポンプ、モータといった機器に対して使われます。データ収集は監視プロセスに欠かせない要素であり、Industry 4.0における生産現場の円滑な運営に役立ちます。

    • 予防保全について

      予防保全とは、基本的には計画され、予定された保全のことをいいます。これは予想される設備の状態、すなわち一般的には状態監視システムと統計的プロセス制御を通して得られる稼働年数やシステム利用状況に基づいて実施されます。しかし、これは不要な保全につながることがあります。機器に保全が必要ない場合もあるためです。予防保全を採用する場合、生産現場は受け身の保全に頼っているということになります。また予防保全では、機器の1つに障害が発生した後の障害診断に頼ることになります。障害診断は例えば、潤滑剤分析やオイル分析を通して実施します。

      主な違い

      予防保全と予知保全の違いは、予知保全システムでは状態監視センサが設備内のデータ収集を担当し、損耗のパターンを特定することで、障害の予測に向けたより的確なアプローチが実現するという点にあります。この際に、統計的監視を用いることもできますが、このような予測モデルでは、機械学習アルゴリズムが動作するニューラルネットワークを使って、データ内のパターンを特定することもできます。続いて予知保全では、システムの正常性を監視することで、予防保全の予定を立てられるようにします。

      予知保全のメリットと予防保全
      予知保全と予防保全

      状態監視センサの果たす重要な役割

      温度センサなどの状態監視センサは、予測分析に不可欠な要素です。温度の上昇は、障害を検出する上で鍵となる因子です。わずかな上昇でも、将来の信頼性の問題を指し示している可能性があります。これは機器内のプローブによっても検出できますが、離れた場所からでも、赤外線サーモグラフィによって確認できます。このようなサーマル・イメージングでは、マシン・ビジョン解析技法を用いることで、プローブでは捕捉できなかった機器内のホットスポットも示すことができます。

      予知保全センサ

      振動モニタも、潜在的な問題を明らかにするために利用できます。振動分析によって、回転機械の高調波周波数に生じた変化が明らかになれば、状態監視ツールは機器の劣化の進行度合いを予測モデルに対してマッピングできます。

      予知保全戦略による費用節約

      予知保全戦略を使って、上に述べたようなデータをすべて組み合わせれば、管理された方法に基づいて機械を生産ラインから外し、修理することが可能になるため、ライン停止につながる最悪の障害を予防できます。その結果、時間に余裕を持って予備部品を発注し、計画されたダウンタイムへの準備を整えられるようになるため、保全コストを削減し、費用の節約に貢献できます。例えば風力タービンの場合、遠隔状態監視システムによって特定されたコンポーネントは、電力への需要が低いときを選んで取り替えられます。

      予知保全ツールはインダストリアルIoT(IIoT)にとって不可欠の要素となりつつあります。リアルタイムの状態監視手法とさまざまなタイプのデータ分析に基づく効果的な予知保全戦略によって、よりコスト効率の高い修繕戦略が実現します。

STの製品

STは、広帯域幅の機械的周波数検出、信頼性、最高105℃までのセンシングの安定性と正確な動作、および低ノイズと低消費電力を重視し、振動および環境センシングに最適な専用の産業用モーションMEMS製品を開発することにより、クラス最高の小型かつコスト効率に優れたIndustry 4.0対応の有線および無線センサ・ネットワーク・ソリューションを可能にしています。

このセンサ・システムは通常、24V DC電源で給電され、センサの駆動には追加のパワー・マネージメントが必要です。そうしたセンサ・ノードは、デジタル(IO-Linkなど)またはアナログ出力を特徴とします。アナログ・センサは、一般にオペアンプで信号調整され、マイクロコントローラのADC(STM8やSTM32など)に接続されます。

    • STEVAL-BFA001V1B (smart industrial sensor) and STEVAL-IDP004V1 (multi-port IO-Link evaluation board) make condition monitoring and predictive maintenance of up to 4 nodes simultaneously.

      This use-case features a PC connection via RS485 with the STEVAL-IDP004V1 multi-port IO-Link interface. The PC GUI allows the monitoring of 4 nodes: pressure, humidity, temperature and 3-axis vibration (where you can adjust thresholds and other settings) under inspection with the powerful libraries embedded in the STEVAL-BFA001V1B software package.

      Features

      • 3-axis MEMS accelerometer:
        •     time domain : speed RMS and acceleration peak
        •     frequency domain: up to 3 kHz FFT with programmable size, averaging, overlapping and windowing
      • MEMS microphone:
        •     sound pressure level (SPL)
        •     up to 20kHz FFT with pre-defined averaging and windowing
      • Pressure, relative humidity and temperature monitoring
      • Configurable thresholds for key parameters
      • Data logging capability through PC GUI



      Solution Components
      製品型番 概要 ステータス Core Products Price (US$)*
      Order / Download
      Buy All
      STEVAL-BFA001V1B

      Key features

      • Compact solution for condition monitoring and predictive maintenance based on 3D digital accelerometer, environmental and acoustic MEMS sensors
      • Main supply voltage: 18 V - 32 V
      • Main components:
        • 32-bit ARM® Cortex® -M4 core for signal processing and analysis (STM32F469AI)
        • iNEMO 6DoF (ISM330DLC)
        • Absolute digital pressure sensor (LPS22HB)
        • Relative humidity and temperature sensors (HTS221)
        • Digital microphone sensors (MP34DT05-A)
        • IO-Link PHY device (L6362A)
        • EEPROM (M95M01-DF) for data storage
        • Step-down switching regulator and LDO regulator (L6984 and LDK220)
      • Complete set of firmware demo examples based on 3D accelerometer library with advanced frequency and time domain signal processing for predictive maintenance, including:
        • Programmable FFT size (512, 1024, 2048)
        • Programmable FFT averaging
        • Programmable overlapping
        • Programmable windowing (Flat Top, Hanning, Hamming)
        • Speed RMS moving average, acceleration max. peak
        • Programmable threshold for warning and alarm conditions in spectral band
      • Microphone algorithms for:
        • PDM to PCM
        • Sound pressure
        • Audio FFT
      • IO-Link PHY using the L6362A Device transceiver for data communication with host unit
      • M12 industrial connector
      • SWD connector for debugging and programming capability
      • リセットボタン
      • Expansion connector with GPIO, ADC, I2C bus
      • Designed to meet IEC industrial standard requirements
      • WEEE compliant
      • RoHS compliant

      続きを読む

      Predictive maintenance kit with sensors and IO-Link capability
      Active
      HTS221, ISM330DLC, LP25HB, M95M01-DF, MP34DT05-A, L6362A 117.60 購入
      STEVAL-IDP003V1

      Key features

      • Main supply voltage: 32 V maximum
      • STM32L071CZ microcontroller
      • IO-Link PHY using the L6362A device for data communication with host unit
      • DC-DC converter and linear regulator on board
      • Integrated reverse polarity protection on L6362A ICs
      • Multi-sensor connection
      • 400 kHz I²C communication
      • PCB designed to accept real industrial sensors (8 mm x 70 mm, with 0.8 mm thickness)
      • Designed to meet IEC industrial standard requirements
      • RoHS compliant

      続きを読む

      IO-Link industrial modular sensor board based on L6362A
      Active
      L6362A 106.58 購入
      STEVAL-IDP004V1

      Key features

      • Main supply voltage 32 V maximum
      • 4 L6360 IO-Link master devices
      • RS-485 serial interface
      • CAN serial interface
      • USB interface
      • DC-DC converter
      • On-board reverse polarity protection
      • Designed to meet IEC requirement for industrial standards
      • RoHS and WEEE compliant

      続きを読む

      IO-Link master multi-port evaluation board based on L6360
      Active
      L6360 123.73 購入
      STSW-BFA001V1

      Key features

      • Set of firmware examples to build applications for condition monitoring and predictive maintenance based on 3D digital accelerometer, environmental and acoustic MEMS sensors
      • Middleware including algorithms for advanced time and frequency domain signal processing for vibration analysis
        • Programmable FFT size (512, 1024 or 2048 points)
        • Programmable FFT averaging and overlapping
        • Programmable windowing (Flat Top, Hanning, Hamming)
        • Speed RMS moving average, acceleration max peak
      • Middleware integrating microphone algorithms for:
        • PDM to PCM
        • Sound pressure
        • Audio FFT
      • Firmware package developed for STM32F469AI with easy portability across different MCU families
      • PC data monitoring through any free terminal emulator
      • Sample demonstration firmware to communicate with STEVAL-IDP004V1 IO-Link-master-capable multi-port evaluation board and dedicated PC GUI

      続きを読む


      STSW-BFA001V1
      STSW-BFA001V1
      Software package for STEVAL-BFA001V1B
      Active
      -
      ソフトウェア
      製品型番 Software Version 製品ステータス サプライヤ ダウンロード
      STSW-BFA001V1 1.1.0 Active ST
      STSW-IO-LINK

      Key features

      • Firmware package developed for STM32 microcontroller ARM® Cortex® -M0+ and ARM Cortex-M3
      • Compliant with STM32Cube framework
      • Portable across other STM32 platforms
      • PC interface based on RS-485 communication
      • Communication layer for exchanging data between master and sensor nodes
      • Sensor configuration and sensor data acquisition
      • Fast Fourier Transform (FFT) calculation to evaluate the vibration spectrum

      続きを読む


      STSW-IO-LINK
      STSW-IO-LINK
      IO-Link demonstration kit firmware
      Active
      -
      ソフトウェア
      製品型番 Software Version 製品ステータス サプライヤ ダウンロード
      STSW-IO-LINK 1.1.1 Active ST
      STEVAL-BFA001V1B

      説明 :

      Predictive maintenance kit with sensors and IO-Link capability

      Price (US$)*

      117.60

      Key features

      • Compact solution for condition monitoring and predictive maintenance based on 3D digital accelerometer, environmental and acoustic MEMS sensors
      • Main supply voltage: 18 V - 32 V
      • Main components:
        • 32-bit ARM® Cortex® -M4 core for signal processing and analysis (STM32F469AI)
        • iNEMO 6DoF (ISM330DLC)
        • Absolute digital pressure sensor (LPS22HB)
        • Relative humidity and temperature sensors (HTS221)
        • Digital microphone sensors (MP34DT05-A)
        • IO-Link PHY device (L6362A)
        • EEPROM (M95M01-DF) for data storage
        • Step-down switching regulator and LDO regulator (L6984 and LDK220)
      • Complete set of firmware demo examples based on 3D accelerometer library with advanced frequency and time domain signal processing for predictive maintenance, including:
        • Programmable FFT size (512, 1024, 2048)
        • Programmable FFT averaging
        • Programmable overlapping
        • Programmable windowing (Flat Top, Hanning, Hamming)
        • Speed RMS moving average, acceleration max. peak
        • Programmable threshold for warning and alarm conditions in spectral band
      • Microphone algorithms for:
        • PDM to PCM
        • Sound pressure
        • Audio FFT
      • IO-Link PHY using the L6362A Device transceiver for data communication with host unit
      • M12 industrial connector
      • SWD connector for debugging and programming capability
      • リセットボタン
      • Expansion connector with GPIO, ADC, I2C bus
      • Designed to meet IEC industrial standard requirements
      • WEEE compliant
      • RoHS compliant

      続きを読む

      STEVAL-IDP003V1

      説明 :

      IO-Link industrial modular sensor board based on L6362A

      Price (US$)*

      106.58

      Key features

      • Main supply voltage: 32 V maximum
      • STM32L071CZ microcontroller
      • IO-Link PHY using the L6362A device for data communication with host unit
      • DC-DC converter and linear regulator on board
      • Integrated reverse polarity protection on L6362A ICs
      • Multi-sensor connection
      • 400 kHz I²C communication
      • PCB designed to accept real industrial sensors (8 mm x 70 mm, with 0.8 mm thickness)
      • Designed to meet IEC industrial standard requirements
      • RoHS compliant

      続きを読む

      STEVAL-IDP004V1

      説明 :

      IO-Link master multi-port evaluation board based on L6360

      Price (US$)*

      123.73

      Key features

      • Main supply voltage 32 V maximum
      • 4 L6360 IO-Link master devices
      • RS-485 serial interface
      • CAN serial interface
      • USB interface
      • DC-DC converter
      • On-board reverse polarity protection
      • Designed to meet IEC requirement for industrial standards
      • RoHS and WEEE compliant

      続きを読む

      STSW-BFA001V1

      説明 :

      Software package for STEVAL-BFA001V1B

      Price (US$)*

      -
      ソフトウェア

      Key features

      • Set of firmware examples to build applications for condition monitoring and predictive maintenance based on 3D digital accelerometer, environmental and acoustic MEMS sensors
      • Middleware including algorithms for advanced time and frequency domain signal processing for vibration analysis
        • Programmable FFT size (512, 1024 or 2048 points)
        • Programmable FFT averaging and overlapping
        • Programmable windowing (Flat Top, Hanning, Hamming)
        • Speed RMS moving average, acceleration max peak
      • Middleware integrating microphone algorithms for:
        • PDM to PCM
        • Sound pressure
        • Audio FFT
      • Firmware package developed for STM32F469AI with easy portability across different MCU families
      • PC data monitoring through any free terminal emulator
      • Sample demonstration firmware to communicate with STEVAL-IDP004V1 IO-Link-master-capable multi-port evaluation board and dedicated PC GUI

      続きを読む


      STSW-BFA001V1
      STSW-BFA001V1
      製品型番 Software Version 製品ステータス サプライヤ ダウンロード
      STSW-BFA001V1 1.1.0 Active ST
      STSW-IO-LINK

      説明 :

      IO-Link demonstration kit firmware

      Price (US$)*

      -
      ソフトウェア

      Key features

      • Firmware package developed for STM32 microcontroller ARM® Cortex® -M0+ and ARM Cortex-M3
      • Compliant with STM32Cube framework
      • Portable across other STM32 platforms
      • PC interface based on RS-485 communication
      • Communication layer for exchanging data between master and sensor nodes
      • Sensor configuration and sensor data acquisition
      • Fast Fourier Transform (FFT) calculation to evaluate the vibration spectrum

      続きを読む


      STSW-IO-LINK
      製品型番 Software Version 製品ステータス サプライヤ ダウンロード
      STSW-IO-LINK 1.1.1 Active ST
    • FP-IND-PREDMNT1 is an STM32Cube function pack with algorithms for time and frequency domain signal processing and analysis of 3D digital accelerometers. A sensor node for condition monitoring and predictive maintenance applications can be developed with this function pack.

      Features

      •  3-axis MEMS accelerometer:
        •     time domain: speed RMS and acceleration peak
        •     frequency domain: up to 1 kHz FFT with programmable size, averaging, overlapping and windowing
      • MEMS microphone:
        •     sound pressure level (SPL)
        •     up to 20kHz FFT with pre-defined averaging and windowing
      • Pressure, relative humidity and temperature monitoring
      • Configurable thresholds for key parameters
      • Data logging through BLE App



      Solution Components
      製品型番 概要 ステータス Core Products Price (US$)*
      Order / Download
      NUCLEO-F446RE

      Key features

      • Common features
        • STM32 microcontroller in LQFP64 package
        • 1 user LED shared with Arduino™
        • 1 user and 1 reset push-buttons
        • 32.768 kHz crystal oscillator
        • Board connectors:Arduino™ Uno V3 expansion connectorST morpho extension pin headers for full access to all STM32 I/Os
        • Flexible power-supply options: ST-LINK, USB VBUS or external sources
        • On-board ST-LINK debugger/programmer with USB re-enumeration capability: mass storage, Virtual COM port and debug port
        • Comprehensive free software libraries and examples available with the STM32Cube MCU Package
        • Support of a wide choice of Integrated Development Environments (IDEs) including IAR™, Keil® and GCC-based IDEs
      • Board-specific features
        • External SMPS to generate Vcore logic supply
        • 24 MHz HSE
        • Board connectors:External SMPS experimentation dedicated connectorMicro-AB or Mini-AB USB connector for the ST-LINKMIPI® debug connector
        • Arm® Mbed Enabled™ compliant

      続きを読む

      STM32 Nucleo-64 development board with STM32F446RE MCU, supports Arduino and ST morpho connectivity
      Active
      STM32F446RE 13.72 購入
      X-NUCLEO-CCA02M1

      Key features

      • 2 on-board MP34DT01-M digital MEMS microphones
      • 6 slots to plug in digital microphone coupon boards such as STEVAL-MKI129Vx and STEVAL-MKI155Vx
      • Synchronized acquisition and streaming of up to 4 microphones
      • Free comprehensive development firmware library and audio capture plus USB streaming sample application which is compatible with STM32Cube firmware
      • Compatible with STM32 Nucleo boards
      • Equipped with ST morpho connector (upwards and downwards)
      • Equipped with Arduino UNO R3 connector (upwards) to allow multiple boards
      • RoHS compliant

      続きを読む

      Digital MEMS microphones expansion board based on MP34DT01-M for STM32 Nucleo.
      Active
      MP34DT01-M 16.0
      X-NUCLEO-IKS01A2

      Key features

      • LSM6DSL MEMS 3D accelerometer (±2/±4/±8/±16 g) and 3D gyroscope (±125/±245/±500/±1000/±2000 dps)
      • LSM303AGR MEMS 3D accelerometer (±2/±4/±8/±16 g) and MEMS3D magnetometer (±50 gauss)
      • LPS22HB MEMS pressure sensor, 260-1260 hPa absolute digital output barometer
      • HTS221: capacitive digital relative humidity and temperature
      • DIL24 socket for additional MEMS adapters and other sensors
      • Free comprehensive development firmware library and example for all sensors compatible with STM32Cube firmware
      • I²C sensor hub features on LSM6DSL available
      • Compatible with STM32 Nucleo boards
      • Equipped with Arduino UNO R3 connector
      • RoHS compliant

      続きを読む

      Motion MEMS and environmental sensor expansion board for STM32 Nucleo
      Active
      LSM6DSL; LSM303AGR; LPS22HB; HTS221 18.38 購入
      X-NUCLEO-IDB05A1

      Key features

      • STM32 expansion board based on the SPBTLE-RF module for STM32 Nucleo
      • X-NUCLEO-IDB05A1 contains FCC and IC certified module SPBTLE-RF (FCC ID: S9NSPBTLERF and IC: 8976C-SPBTLERF)
      • SPBTLE-RF:
        • Bluetooth Low Energy FCC and IC certified module based on Bluetooth® SMART 4.1 network processor BlueNRG-MS
        • Integrated Balun (BALF-NRG-01D3)
        • Chip antenna
      • Compatible with STM32 Nucleo boards
      • Equipped with Arduino UNO R3 connector
      • Scalable solution, capable of cascading multiple boards for larger systems
      • Free comprehensive development firmware library and example for BlueNRG-MS, compatible with STM32Cube firmware
      • RoHS compliant

      続きを読む

      Bluetooth Low Energy expansion board based on SPBTLE-RF module for STM32 Nucleo
      Active
      SPBTLE-RF; BlueNRG-MS; BALF-NRG-01D3 12.87 購入
      STEVAL-MKI182V2

      Key features

      • Complete ISM330DLC pinout for a standard DIL 24 socket
      • Fully compatible with STEVAL-MKI109V3 motherboard
      • Changing the resistor settings is also compatible with the STEVAL-MKI109V2 motherboard
      • RoHS compliant

      続きを読む

      ISM330DLC adapter board for a standard DIL24 socket
      Active
      ISM330DLC 15.93 購入
      FP-IND-PREDMNT1

      Key features

      • Complete firmware to develop a sensor node for condition monitoring and predictive maintenance applications, featuring digital or analog microphone, environmental and motion sensors, and performing real-time monitoring of parameters and equipment status via:
        • user terminal by UART (available for the STEVAL-IDP005V1 evaluation board included in the STEVAL-BFA001V1B kit)
        • Wi-Fi connectivity (available for the STEVAL-STWINCSV1 board included in the STEVAL-STWINKT1 kit)
        • BLE connectivity (available for the NUCLEO-F446RE development board and the STEVAL-STWINKT1 kit)
      • Signal processing (MotionSP) middleware for vibration analysis in time domain (speed RMS and acceleration peak) and frequency domain (FFT with programmable size, averaging, overlapping and windowing)
      • PDM to PCM and sound pressure level (SPL) middleware for digital microphones (for NUCLEO-F446RE and STEVAL-BFA001V1B)
      • Acoustic FFT Analysis for NUCLEO-F446RE and STEVAL-BFA001V1B
      • Ultrasound FFT Analysis for STEVAL-STWINKT1
      • Configurable alarm and warning thresholds for key parameters
      • Data logging capability through mobile app or PC serial terminal
      • Compatible with STBLESensor application for Android/iOS, to perform sensor data reading, audio and motion algorithm feature demo, and firmware update over the air (FOTA) (feature available only when using NUCLEO-F446RE and STEVAL-STWINKT1 with BLE connectivity)
      • Compatible with DSH-PREDMNT web-based predictive maintenance dashboard for monitoring sensor data and device status (feature available only when using the STEVAL-STWINKT1 with the STEVAL-STWINWFV1 Wi-Fi adapter)
      • Sample implementation available for the STEVAL-BFA001V1B and STEVAL-STWINKT1 kits
      • Sample implementation available for X-NUCLEO-CCA02M1, X-NUCLEO-IKS01A3 or X-NUCLEO-IKS01A2, STEVAL-MKI182V2 (DIL24 based on ISM330DLC) and X-NUCLEO-IDB05A1 connected to a NUCLEO-F446RE board
      • Easy portability across different MCU families, thanks to STM32Cube
      • Free, user-friendly license terms

      続きを読む


      FP-IND-PREDMNT1
      FP-IND-PREDMNT1
      STM32Cube function pack for multi sensors node with signal processing to enable predictive maintenance
      Active
      -
      ソフトウェア
      製品型番 概要 Software Version サプライヤ GitHub link ダウンロード
      FP-IND-PREDMNT1 STM32Cube function pack for multi sensors node with signal processing to enable predictive maintenance 2.0.0 ST -
      FP-SNS-ALLMEMS2

      Key features

      • Complete firmware to develop an IoT node with BLE connectivity, digital microphone, environmental and motion sensors
      • Middleware libraries for sensor data fusion and accelerometer-based real-time activity recognition, acoustic source localization and beam forming, audio processing and streaming over BLE communication profile, and SD card data logging
      • Compatible with STBLESensor application for Android/iOS, to perform sensor data reading, audio and motion algorithm feature demo, and firmware update over the air (FOTA)
      • Implementation based on the use of an RTOS, targeting ultra-low power consumption use cases with battery operated devices
      • Sample implementation available for STEVAL-BCNKT01V1, STEVAL-MKSBOX1V1 and STEVAL-STLKT01V1 evaluation boards and for X-NUCLEO-CCA02M1, X-NUCLEO-IKS01A2 (or X-NUCLEO-IKS01A3) and X-NUCLEO-IDB05A1 connected to a NUCLEO-F446RE or NUCLEO-L476RG board
      • Easy portability across different MCU families, thanks to STM32Cube
      • Free, user-friendly license terms

      続きを読む


      FP-SNS-ALLMEMS2
      FP-SNS-ALLMEMS2
      STM32Cube function pack for ultra-low power IoT node with BLE connectivity, digital microphone, environmental and motion sensors
      Active
      -
      ソフトウェア
      製品型番 概要 Software Version サプライヤ GitHub link ダウンロード
      FP-SNS-ALLMEMS2 STM32Cube function pack for ultra-low power IoT node with BLE connectivity, digital microphone, environmental and motion sensors 2.0.0 ST -
      X-CUBE-BLE1

      Key features

      • Complete middleware to build Bluetooth low energy applications using BlueNRG-MS device
      • Easy portability across different MCU families, thanks to STM32Cube
      • Numerous examples to aid understanding:
        • Support for Standard Profiles (Peripheral and Central)
        • Support for Apple Notification Center Service (ANCS)
      • Package compatible with STM32CubeMX, can be downloaded from and installed directly into STM32CubeMX
      • Free, user-friendly license terms

      続きを読む


      X-CUBE-BLE1
      X-CUBE-BLE1
      Bluetooth Low Energy software expansion for STM32Cube
      Active
      -
      ソフトウェア
      製品型番 概要 Software Version サプライヤ GitHub link ダウンロード
      X-CUBE-BLE1 Bluetooth Low Energy software expansion for STM32Cube 4.4.0 ST -
      NUCLEO-F446RE

      説明 :

      STM32 Nucleo-64 development board with STM32F446RE MCU, supports Arduino and ST morpho connectivity

      Price (US$)*

      13.72

      Key features

      • Common features
        • STM32 microcontroller in LQFP64 package
        • 1 user LED shared with Arduino™
        • 1 user and 1 reset push-buttons
        • 32.768 kHz crystal oscillator
        • Board connectors:Arduino™ Uno V3 expansion connectorST morpho extension pin headers for full access to all STM32 I/Os
        • Flexible power-supply options: ST-LINK, USB VBUS or external sources
        • On-board ST-LINK debugger/programmer with USB re-enumeration capability: mass storage, Virtual COM port and debug port
        • Comprehensive free software libraries and examples available with the STM32Cube MCU Package
        • Support of a wide choice of Integrated Development Environments (IDEs) including IAR™, Keil® and GCC-based IDEs
      • Board-specific features
        • External SMPS to generate Vcore logic supply
        • 24 MHz HSE
        • Board connectors:External SMPS experimentation dedicated connectorMicro-AB or Mini-AB USB connector for the ST-LINKMIPI® debug connector
        • Arm® Mbed Enabled™ compliant

      続きを読む

      X-NUCLEO-CCA02M1

      説明 :

      Digital MEMS microphones expansion board based on MP34DT01-M for STM32 Nucleo.

      Price (US$)*

      16.0

      Key features

      • 2 on-board MP34DT01-M digital MEMS microphones
      • 6 slots to plug in digital microphone coupon boards such as STEVAL-MKI129Vx and STEVAL-MKI155Vx
      • Synchronized acquisition and streaming of up to 4 microphones
      • Free comprehensive development firmware library and audio capture plus USB streaming sample application which is compatible with STM32Cube firmware
      • Compatible with STM32 Nucleo boards
      • Equipped with ST morpho connector (upwards and downwards)
      • Equipped with Arduino UNO R3 connector (upwards) to allow multiple boards
      • RoHS compliant

      続きを読む

      X-NUCLEO-IKS01A2

      説明 :

      Motion MEMS and environmental sensor expansion board for STM32 Nucleo

      Price (US$)*

      18.38

      Key features

      • LSM6DSL MEMS 3D accelerometer (±2/±4/±8/±16 g) and 3D gyroscope (±125/±245/±500/±1000/±2000 dps)
      • LSM303AGR MEMS 3D accelerometer (±2/±4/±8/±16 g) and MEMS3D magnetometer (±50 gauss)
      • LPS22HB MEMS pressure sensor, 260-1260 hPa absolute digital output barometer
      • HTS221: capacitive digital relative humidity and temperature
      • DIL24 socket for additional MEMS adapters and other sensors
      • Free comprehensive development firmware library and example for all sensors compatible with STM32Cube firmware
      • I²C sensor hub features on LSM6DSL available
      • Compatible with STM32 Nucleo boards
      • Equipped with Arduino UNO R3 connector
      • RoHS compliant

      続きを読む

      X-NUCLEO-IDB05A1

      説明 :

      Bluetooth Low Energy expansion board based on SPBTLE-RF module for STM32 Nucleo

      Price (US$)*

      12.87

      Key features

      • STM32 expansion board based on the SPBTLE-RF module for STM32 Nucleo
      • X-NUCLEO-IDB05A1 contains FCC and IC certified module SPBTLE-RF (FCC ID: S9NSPBTLERF and IC: 8976C-SPBTLERF)
      • SPBTLE-RF:
        • Bluetooth Low Energy FCC and IC certified module based on Bluetooth® SMART 4.1 network processor BlueNRG-MS
        • Integrated Balun (BALF-NRG-01D3)
        • Chip antenna
      • Compatible with STM32 Nucleo boards
      • Equipped with Arduino UNO R3 connector
      • Scalable solution, capable of cascading multiple boards for larger systems
      • Free comprehensive development firmware library and example for BlueNRG-MS, compatible with STM32Cube firmware
      • RoHS compliant

      続きを読む

      STEVAL-MKI182V2

      説明 :

      ISM330DLC adapter board for a standard DIL24 socket

      Price (US$)*

      15.93

      Key features

      • Complete ISM330DLC pinout for a standard DIL 24 socket
      • Fully compatible with STEVAL-MKI109V3 motherboard
      • Changing the resistor settings is also compatible with the STEVAL-MKI109V2 motherboard
      • RoHS compliant

      続きを読む

      FP-IND-PREDMNT1

      説明 :

      STM32Cube function pack for multi sensors node with signal processing to enable predictive maintenance

      Price (US$)*

      -
      ソフトウェア

      Key features

      • Complete firmware to develop a sensor node for condition monitoring and predictive maintenance applications, featuring digital or analog microphone, environmental and motion sensors, and performing real-time monitoring of parameters and equipment status via:
        • user terminal by UART (available for the STEVAL-IDP005V1 evaluation board included in the STEVAL-BFA001V1B kit)
        • Wi-Fi connectivity (available for the STEVAL-STWINCSV1 board included in the STEVAL-STWINKT1 kit)
        • BLE connectivity (available for the NUCLEO-F446RE development board and the STEVAL-STWINKT1 kit)
      • Signal processing (MotionSP) middleware for vibration analysis in time domain (speed RMS and acceleration peak) and frequency domain (FFT with programmable size, averaging, overlapping and windowing)
      • PDM to PCM and sound pressure level (SPL) middleware for digital microphones (for NUCLEO-F446RE and STEVAL-BFA001V1B)
      • Acoustic FFT Analysis for NUCLEO-F446RE and STEVAL-BFA001V1B
      • Ultrasound FFT Analysis for STEVAL-STWINKT1
      • Configurable alarm and warning thresholds for key parameters
      • Data logging capability through mobile app or PC serial terminal
      • Compatible with STBLESensor application for Android/iOS, to perform sensor data reading, audio and motion algorithm feature demo, and firmware update over the air (FOTA) (feature available only when using NUCLEO-F446RE and STEVAL-STWINKT1 with BLE connectivity)
      • Compatible with DSH-PREDMNT web-based predictive maintenance dashboard for monitoring sensor data and device status (feature available only when using the STEVAL-STWINKT1 with the STEVAL-STWINWFV1 Wi-Fi adapter)
      • Sample implementation available for the STEVAL-BFA001V1B and STEVAL-STWINKT1 kits
      • Sample implementation available for X-NUCLEO-CCA02M1, X-NUCLEO-IKS01A3 or X-NUCLEO-IKS01A2, STEVAL-MKI182V2 (DIL24 based on ISM330DLC) and X-NUCLEO-IDB05A1 connected to a NUCLEO-F446RE board
      • Easy portability across different MCU families, thanks to STM32Cube
      • Free, user-friendly license terms

      続きを読む


      FP-IND-PREDMNT1
      FP-IND-PREDMNT1
      製品型番 概要 Software Version サプライヤ GitHub link ダウンロード
      FP-IND-PREDMNT1 STM32Cube function pack for multi sensors node with signal processing to enable predictive maintenance 2.0.0 ST -
      FP-SNS-ALLMEMS2

      説明 :

      STM32Cube function pack for ultra-low power IoT node with BLE connectivity, digital microphone, environmental and motion sensors

      Price (US$)*

      -
      ソフトウェア

      Key features

      • Complete firmware to develop an IoT node with BLE connectivity, digital microphone, environmental and motion sensors
      • Middleware libraries for sensor data fusion and accelerometer-based real-time activity recognition, acoustic source localization and beam forming, audio processing and streaming over BLE communication profile, and SD card data logging
      • Compatible with STBLESensor application for Android/iOS, to perform sensor data reading, audio and motion algorithm feature demo, and firmware update over the air (FOTA)
      • Implementation based on the use of an RTOS, targeting ultra-low power consumption use cases with battery operated devices
      • Sample implementation available for STEVAL-BCNKT01V1, STEVAL-MKSBOX1V1 and STEVAL-STLKT01V1 evaluation boards and for X-NUCLEO-CCA02M1, X-NUCLEO-IKS01A2 (or X-NUCLEO-IKS01A3) and X-NUCLEO-IDB05A1 connected to a NUCLEO-F446RE or NUCLEO-L476RG board
      • Easy portability across different MCU families, thanks to STM32Cube
      • Free, user-friendly license terms

      続きを読む


      FP-SNS-ALLMEMS2
      FP-SNS-ALLMEMS2
      製品型番 概要 Software Version サプライヤ GitHub link ダウンロード
      FP-SNS-ALLMEMS2 STM32Cube function pack for ultra-low power IoT node with BLE connectivity, digital microphone, environmental and motion sensors 2.0.0 ST -
      X-CUBE-BLE1

      説明 :

      Bluetooth Low Energy software expansion for STM32Cube

      Price (US$)*

      -
      ソフトウェア

      Key features

      • Complete middleware to build Bluetooth low energy applications using BlueNRG-MS device
      • Easy portability across different MCU families, thanks to STM32Cube
      • Numerous examples to aid understanding:
        • Support for Standard Profiles (Peripheral and Central)
        • Support for Apple Notification Center Service (ANCS)
      • Package compatible with STM32CubeMX, can be downloaded from and installed directly into STM32CubeMX
      • Free, user-friendly license terms

      続きを読む


      X-CUBE-BLE1
      X-CUBE-BLE1
      製品型番 概要 Software Version サプライヤ GitHub link ダウンロード
      X-CUBE-BLE1 Bluetooth Low Energy software expansion for STM32Cube 4.4.0 ST -
    • Implementation of a smart industrial sensor node is easily achievable with the STEVAL-BFA001V1B.

      An industrial sensor shape form factor PCB featuring our 10-years longevity sensors for the industrial market and a powerful software package where ready-to-use software examples for FFT are available.

      Features

      • 3-axis MEMS accelerometer:
        •     time domain: speed RMS and    acceleration peak
        •     frequency domain: up to 3 kHz FFT with programmable size, averaging, overlapping and windowing
      • MEMS microphone:
        •     sound pressure level (SPL)
        •     up to 20kHz FFT with pre-defined averaging and windowing
      • Pressure, relative humidity and temperature monitoring
      • Configurable thresholds for key parameters
      • Data logging through UART and PC hyper terminal



      Solution Components
      製品型番 概要 ステータス Core Products Price (US$)*
      Order / Download
      STEVAL-BFA001V1B

      Key features

      • Compact solution for condition monitoring and predictive maintenance based on 3D digital accelerometer, environmental and acoustic MEMS sensors
      • Main supply voltage: 18 V - 32 V
      • Main components:
        • 32-bit ARM® Cortex® -M4 core for signal processing and analysis (STM32F469AI)
        • iNEMO 6DoF (ISM330DLC)
        • Absolute digital pressure sensor (LPS22HB)
        • Relative humidity and temperature sensors (HTS221)
        • Digital microphone sensors (MP34DT05-A)
        • IO-Link PHY device (L6362A)
        • EEPROM (M95M01-DF) for data storage
        • Step-down switching regulator and LDO regulator (L6984 and LDK220)
      • Complete set of firmware demo examples based on 3D accelerometer library with advanced frequency and time domain signal processing for predictive maintenance, including:
        • Programmable FFT size (512, 1024, 2048)
        • Programmable FFT averaging
        • Programmable overlapping
        • Programmable windowing (Flat Top, Hanning, Hamming)
        • Speed RMS moving average, acceleration max. peak
        • Programmable threshold for warning and alarm conditions in spectral band
      • Microphone algorithms for:
        • PDM to PCM
        • Sound pressure
        • Audio FFT
      • IO-Link PHY using the L6362A Device transceiver for data communication with host unit
      • M12 industrial connector
      • SWD connector for debugging and programming capability
      • リセットボタン
      • Expansion connector with GPIO, ADC, I2C bus
      • Designed to meet IEC industrial standard requirements
      • WEEE compliant
      • RoHS compliant

      続きを読む

      Predictive maintenance kit with sensors and IO-Link capability
      Active
      HTS221, ISM330DLC, LP25HB, M95M01-DF, MP34DT05-A, L6362A 117.60 購入
      FP-IND-PREDMNT1

      Key features

      • Complete firmware to develop a sensor node for condition monitoring and predictive maintenance applications, featuring digital or analog microphone, environmental and motion sensors, and performing real-time monitoring of parameters and equipment status via:
        • user terminal by UART (available for the STEVAL-IDP005V1 evaluation board included in the STEVAL-BFA001V1B kit)
        • Wi-Fi connectivity (available for the STEVAL-STWINCSV1 board included in the STEVAL-STWINKT1 kit)
        • BLE connectivity (available for the NUCLEO-F446RE development board and the STEVAL-STWINKT1 kit)
      • Signal processing (MotionSP) middleware for vibration analysis in time domain (speed RMS and acceleration peak) and frequency domain (FFT with programmable size, averaging, overlapping and windowing)
      • PDM to PCM and sound pressure level (SPL) middleware for digital microphones (for NUCLEO-F446RE and STEVAL-BFA001V1B)
      • Acoustic FFT Analysis for NUCLEO-F446RE and STEVAL-BFA001V1B
      • Ultrasound FFT Analysis for STEVAL-STWINKT1
      • Configurable alarm and warning thresholds for key parameters
      • Data logging capability through mobile app or PC serial terminal
      • Compatible with STBLESensor application for Android/iOS, to perform sensor data reading, audio and motion algorithm feature demo, and firmware update over the air (FOTA) (feature available only when using NUCLEO-F446RE and STEVAL-STWINKT1 with BLE connectivity)
      • Compatible with DSH-PREDMNT web-based predictive maintenance dashboard for monitoring sensor data and device status (feature available only when using the STEVAL-STWINKT1 with the STEVAL-STWINWFV1 Wi-Fi adapter)
      • Sample implementation available for the STEVAL-BFA001V1B and STEVAL-STWINKT1 kits
      • Sample implementation available for X-NUCLEO-CCA02M1, X-NUCLEO-IKS01A3 or X-NUCLEO-IKS01A2, STEVAL-MKI182V2 (DIL24 based on ISM330DLC) and X-NUCLEO-IDB05A1 connected to a NUCLEO-F446RE board
      • Easy portability across different MCU families, thanks to STM32Cube
      • Free, user-friendly license terms

      続きを読む


      FP-IND-PREDMNT1
      FP-IND-PREDMNT1
      STM32Cube function pack for multi sensors node with signal processing to enable predictive maintenance
      Active
      -
      ソフトウェア
      製品型番 概要 Software Version サプライヤ GitHub link ダウンロード
      FP-IND-PREDMNT1 STM32Cube function pack for multi sensors node with signal processing to enable predictive maintenance 2.0.0 ST -
      STEVAL-BFA001V1B

      説明 :

      Predictive maintenance kit with sensors and IO-Link capability

      Price (US$)*

      117.60

      Key features

      • Compact solution for condition monitoring and predictive maintenance based on 3D digital accelerometer, environmental and acoustic MEMS sensors
      • Main supply voltage: 18 V - 32 V
      • Main components:
        • 32-bit ARM® Cortex® -M4 core for signal processing and analysis (STM32F469AI)
        • iNEMO 6DoF (ISM330DLC)
        • Absolute digital pressure sensor (LPS22HB)
        • Relative humidity and temperature sensors (HTS221)
        • Digital microphone sensors (MP34DT05-A)
        • IO-Link PHY device (L6362A)
        • EEPROM (M95M01-DF) for data storage
        • Step-down switching regulator and LDO regulator (L6984 and LDK220)
      • Complete set of firmware demo examples based on 3D accelerometer library with advanced frequency and time domain signal processing for predictive maintenance, including:
        • Programmable FFT size (512, 1024, 2048)
        • Programmable FFT averaging
        • Programmable overlapping
        • Programmable windowing (Flat Top, Hanning, Hamming)
        • Speed RMS moving average, acceleration max. peak
        • Programmable threshold for warning and alarm conditions in spectral band
      • Microphone algorithms for:
        • PDM to PCM
        • Sound pressure
        • Audio FFT
      • IO-Link PHY using the L6362A Device transceiver for data communication with host unit
      • M12 industrial connector
      • SWD connector for debugging and programming capability
      • リセットボタン
      • Expansion connector with GPIO, ADC, I2C bus
      • Designed to meet IEC industrial standard requirements
      • WEEE compliant
      • RoHS compliant

      続きを読む

      FP-IND-PREDMNT1

      説明 :

      STM32Cube function pack for multi sensors node with signal processing to enable predictive maintenance

      Price (US$)*

      -
      ソフトウェア

      Key features

      • Complete firmware to develop a sensor node for condition monitoring and predictive maintenance applications, featuring digital or analog microphone, environmental and motion sensors, and performing real-time monitoring of parameters and equipment status via:
        • user terminal by UART (available for the STEVAL-IDP005V1 evaluation board included in the STEVAL-BFA001V1B kit)
        • Wi-Fi connectivity (available for the STEVAL-STWINCSV1 board included in the STEVAL-STWINKT1 kit)
        • BLE connectivity (available for the NUCLEO-F446RE development board and the STEVAL-STWINKT1 kit)
      • Signal processing (MotionSP) middleware for vibration analysis in time domain (speed RMS and acceleration peak) and frequency domain (FFT with programmable size, averaging, overlapping and windowing)
      • PDM to PCM and sound pressure level (SPL) middleware for digital microphones (for NUCLEO-F446RE and STEVAL-BFA001V1B)
      • Acoustic FFT Analysis for NUCLEO-F446RE and STEVAL-BFA001V1B
      • Ultrasound FFT Analysis for STEVAL-STWINKT1
      • Configurable alarm and warning thresholds for key parameters
      • Data logging capability through mobile app or PC serial terminal
      • Compatible with STBLESensor application for Android/iOS, to perform sensor data reading, audio and motion algorithm feature demo, and firmware update over the air (FOTA) (feature available only when using NUCLEO-F446RE and STEVAL-STWINKT1 with BLE connectivity)
      • Compatible with DSH-PREDMNT web-based predictive maintenance dashboard for monitoring sensor data and device status (feature available only when using the STEVAL-STWINKT1 with the STEVAL-STWINWFV1 Wi-Fi adapter)
      • Sample implementation available for the STEVAL-BFA001V1B and STEVAL-STWINKT1 kits
      • Sample implementation available for X-NUCLEO-CCA02M1, X-NUCLEO-IKS01A3 or X-NUCLEO-IKS01A2, STEVAL-MKI182V2 (DIL24 based on ISM330DLC) and X-NUCLEO-IDB05A1 connected to a NUCLEO-F446RE board
      • Easy portability across different MCU families, thanks to STM32Cube
      • Free, user-friendly license terms

      続きを読む


      FP-IND-PREDMNT1
      FP-IND-PREDMNT1
      製品型番 概要 Software Version サプライヤ GitHub link ダウンロード
      FP-IND-PREDMNT1 STM32Cube function pack for multi sensors node with signal processing to enable predictive maintenance 2.0.0 ST -

製品型番
概要
STEVAL-IDP004V1 IO-Link master multi-port evaluation board based on L6360 Quick view

主な特徴

  • Main supply voltage 32 V maximum
  • 4 L6360 IO-Link master devices
  • RS-485 serial interface
  • CAN serial interface
  • USB interface
  • DC-DC converter
  • On-board reverse polarity protection
  • Designed to meet IEC requirement for industrial standards
  • RoHS and WEEE compliant

さらに表示

画像


注目リソース

Schematics BOM Gerber
STEVAL-BFA001V1B Predictive maintenance kit with sensors and IO-Link capability Quick view

主な特徴

  • Compact solution for condition monitoring and predictive maintenance based on 3D digital accelerometer, environmental and acoustic MEMS sensors
  • Main supply voltage: 18 V - 32 V
  • Main components:
    • 32-bit ARM® Cortex® -M4 core for signal processing and analysis (STM32F469AI)
    • iNEMO 6DoF (ISM330DLC)
    • Absolute digital pressure sensor (LPS22HB)
    • Relative humidity and temperature sensors (HTS221)
    • Digital microphone sensors (MP34DT05-A)
    • IO-Link PHY device (L6362A)
    • EEPROM (M95M01-DF) for data storage
    • Step-down switching regulator and LDO regulator (L6984 and LDK220)
  • Complete set of firmware demo examples based on 3D accelerometer library with advanced frequency and time domain signal processing for predictive maintenance, including:
    • Programmable FFT size (512, 1024, 2048)
    • Programmable FFT averaging
    • Programmable overlapping
    • Programmable windowing (Flat Top, Hanning, Hamming)
    • Speed RMS moving average, acceleration max. peak
    • Programmable threshold for warning and alarm conditions in spectral band
  • Microphone algorithms for:
    • PDM to PCM
    • Sound pressure
    • Audio FFT
  • IO-Link PHY using the L6362A Device transceiver for data communication with host unit
  • M12 industrial connector
  • SWD connector for debugging and programming capability
  • リセットボタン
  • Expansion connector with GPIO, ADC, I2C bus
  • Designed to meet IEC industrial standard requirements
  • WEEE compliant
  • RoHS compliant

さらに表示

画像


注目リソース

Schematics BOM Gerber
X-NUCLEO-IKS01A2 Motion MEMS and environmental sensor expansion board for STM32 Nucleo Quick view

主な特徴

  • LSM6DSL MEMS 3D accelerometer (±2/±4/±8/±16 g) and 3D gyroscope (±125/±245/±500/±1000/±2000 dps)
  • LSM303AGR MEMS 3D accelerometer (±2/±4/±8/±16 g) and MEMS3D magnetometer (±50 gauss)
  • LPS22HB MEMS pressure sensor, 260-1260 hPa absolute digital output barometer
  • HTS221: capacitive digital relative humidity and temperature
  • DIL24 socket for additional MEMS adapters and other sensors
  • Free comprehensive development firmware library and example for all sensors compatible with STM32Cube firmware
  • I²C sensor hub features on LSM6DSL available
  • Compatible with STM32 Nucleo boards
  • Equipped with Arduino UNO R3 connector
  • RoHS compliant

さらに表示

画像


注目リソース

Schematics BOM Gerber
製品型番
STEVAL-IDP004V1

IO-Link master multi-port evaluation board based on L6360

主な特徴

  • Main supply voltage 32 V maximum
  • 4 L6360 IO-Link master devices
  • RS-485 serial interface
  • CAN serial interface
  • USB interface
  • DC-DC converter
  • On-board reverse polarity protection
  • Designed to meet IEC requirement for industrial standards
  • RoHS and WEEE compliant

さらに表示

画像


注目リソース

Schematics BOM Gerber
STEVAL-BFA001V1B

Predictive maintenance kit with sensors and IO-Link capability

主な特徴

  • Compact solution for condition monitoring and predictive maintenance based on 3D digital accelerometer, environmental and acoustic MEMS sensors
  • Main supply voltage: 18 V - 32 V
  • Main components:
    • 32-bit ARM® Cortex® -M4 core for signal processing and analysis (STM32F469AI)
    • iNEMO 6DoF (ISM330DLC)
    • Absolute digital pressure sensor (LPS22HB)
    • Relative humidity and temperature sensors (HTS221)
    • Digital microphone sensors (MP34DT05-A)
    • IO-Link PHY device (L6362A)
    • EEPROM (M95M01-DF) for data storage
    • Step-down switching regulator and LDO regulator (L6984 and LDK220)
  • Complete set of firmware demo examples based on 3D accelerometer library with advanced frequency and time domain signal processing for predictive maintenance, including:
    • Programmable FFT size (512, 1024, 2048)
    • Programmable FFT averaging
    • Programmable overlapping
    • Programmable windowing (Flat Top, Hanning, Hamming)
    • Speed RMS moving average, acceleration max. peak
    • Programmable threshold for warning and alarm conditions in spectral band
  • Microphone algorithms for:
    • PDM to PCM
    • Sound pressure
    • Audio FFT
  • IO-Link PHY using the L6362A Device transceiver for data communication with host unit
  • M12 industrial connector
  • SWD connector for debugging and programming capability
  • リセットボタン
  • Expansion connector with GPIO, ADC, I2C bus
  • Designed to meet IEC industrial standard requirements
  • WEEE compliant
  • RoHS compliant

さらに表示

画像


注目リソース

Schematics BOM Gerber
X-NUCLEO-IKS01A2

Motion MEMS and environmental sensor expansion board for STM32 Nucleo

主な特徴

  • LSM6DSL MEMS 3D accelerometer (±2/±4/±8/±16 g) and 3D gyroscope (±125/±245/±500/±1000/±2000 dps)
  • LSM303AGR MEMS 3D accelerometer (±2/±4/±8/±16 g) and MEMS3D magnetometer (±50 gauss)
  • LPS22HB MEMS pressure sensor, 260-1260 hPa absolute digital output barometer
  • HTS221: capacitive digital relative humidity and temperature
  • DIL24 socket for additional MEMS adapters and other sensors
  • Free comprehensive development firmware library and example for all sensors compatible with STM32Cube firmware
  • I²C sensor hub features on LSM6DSL available
  • Compatible with STM32 Nucleo boards
  • Equipped with Arduino UNO R3 connector
  • RoHS compliant

さらに表示

画像


注目リソース

Schematics BOM Gerber
00 ファイルがダウンロード用に選択されています

技術文書

    • 概要 バージョン サイズ アクション
      AN5146
      IIS3DHHC: high-resolution, high-stability 3-axis digital accelerometer
      2.0
      411.03 KB
      PDF
      AN5041
      IO-Link evaluation kit using STEVAL-IDP004V1 master evaluation board and STEVAL-IDP003V1 kit
      3.0
      1.96 MB
      PDF
      AN5063
      LPS33HW digital pressure sensor: guidelines for system integration
      1.0
      681.3 KB
      PDF
      AN4113
      Managing the Driver Enable signal for RS-485 and IO-Link communications with the STM32F05x USART
      1.3
      142.25 KB
      PDF
      AN3070
      Managing the Driver Enable signal for RS-485 and IO-Link communications with the STM32™’s USART
      1.4
      188.96 KB
      PDF
      AN4075
      STEVAL-IFP016V2 IO-Link communication master transceiver demonstration board
      1.0
      409.41 KB
      PDF
      AN5146

      IIS3DHHC: high-resolution, high-stability 3-axis digital accelerometer

      AN5041

      IO-Link evaluation kit using STEVAL-IDP004V1 master evaluation board and STEVAL-IDP003V1 kit

      AN5063

      LPS33HW digital pressure sensor: guidelines for system integration

      AN4113

      Managing the Driver Enable signal for RS-485 and IO-Link communications with the STM32F05x USART

      AN3070

      Managing the Driver Enable signal for RS-485 and IO-Link communications with the STM32™’s USART

      AN4075

      STEVAL-IFP016V2 IO-Link communication master transceiver demonstration board

    • 概要 バージョン サイズ アクション
      DT0064
      Noise analysis and identification in MEMS sensors, Allan, Time, Hadamard, Overlapping, Modified, Total variance
      1.0
      616.94 KB
      PDF
      DT0064

      Noise analysis and identification in MEMS sensors, Allan, Time, Hadamard, Overlapping, Modified, Total variance

プレゼンテーション & トレーニング資料

    • 概要 バージョン サイズ アクション
      FP-CLD-AWS1 quick start guide 2.1
      5.55 MB
      PDF
      FP-CLD-AZURE1 quick start guide 3.3
      4.84 MB
      PDF
      FP-CLD-WATSON1 Quick start guide 2.4
      3.26 MB
      PDF
      FP-NET-BLESTAR1 Quick start guide 1.6
      3.83 MB
      PDF
      IoT: Cloud Connectivity Expansion Packages for STM32Cube 1.0
      895.03 KB
      PDF
      LPWAN Technologies For IoT Francesco Doddo 1.0
      7.55 MB
      PDF
      STEVAL-BFA001V1B GETTING STARTED GUIDE 1.1
      3.41 MB
      PDF
      STEVAL-STLKT01V1 Quick start guide 2.4
      2.02 MB
      PDF

      FP-CLD-AWS1 quick start guide

      FP-CLD-AZURE1 quick start guide

      FP-CLD-WATSON1 Quick start guide

      FP-NET-BLESTAR1 Quick start guide

      IoT: Cloud Connectivity Expansion Packages for STM32Cube

      LPWAN Technologies For IoT Francesco Doddo

      STEVAL-BFA001V1B GETTING STARTED GUIDE

      STEVAL-STLKT01V1 Quick start guide

関連資料

    • 概要 バージョン サイズ アクション
      L6360 & L6362A - Industry 4.0をサポート 07.2018
      272.77 KB
      PDF
      MEMS sensors for smart industry 4.0 2.1
      874.15 KB
      PDF
      S2-LP:Ultra-low-power, high-performance, sub-1GHz RF transceiver 1.2
      664.12 KB
      PDF
      STSAFE-TPM Standardized solution for trusted devices 1.0
      226.91 KB
      PDF
      SensorTile an IoT design lab
      893.85 KB
      PDF

      L6360 & L6362A - Industry 4.0をサポート

      MEMS sensors for smart industry 4.0

      S2-LP:Ultra-low-power, high-performance, sub-1GHz RF transceiver

      STSAFE-TPM Standardized solution for trusted devices

      SensorTile an IoT design lab

    • 概要 バージョン サイズ アクション
      Brochure Secure MCUs - Secure Solutions 1.0
      1.1 MB
      PDF
      Intelligent power switches (IPS) 04.2018
      627.09 KB
      PDF
      IO-Link向け ソリューション 08.2017
      1.12 MB
      PDF
      スマート・インダストリ向け 製品 & ソリューション ガイド 3.1
      3.41 MB
      PDF
      STM32L series - Ultra-low-power 32-bit MCUs 17.5
      1.66 MB
      PDF

      Brochure Secure MCUs - Secure Solutions

      Intelligent power switches (IPS)

      IO-Link向け ソリューション

      スマート・インダストリ向け 製品 & ソリューション ガイド

      STM32L series - Ultra-low-power 32-bit MCUs

    • 概要 バージョン サイズ アクション
      Capacitive MEMS accelerometer for condition monitoring 1.0
      3.35 MB
      PDF

      Capacitive MEMS accelerometer for condition monitoring

ソフトウェア製品

    • 製品型番

      STM32Cube function pack for multi sensors node with signal processing to enable predictive maintenance

eDesignSuite

コンバータ

Input

V This option is required. And must be less than or equal to Volt. Max [V]
V This option is required. And must be greater than or equal to Volt. Min [V]

Output Power

V This option is required and must be a number.
A This option is required and must be a number.

MEMS and Sensors

品名 概要
IIS2DH 3-axis digital accelerometer, ultra low-power high performance MEMS motion sensor
IIS3DHHC High-resolution, high-stability 3-axis digital inclinometer for industrial applications
品名
3-axis digital accelerometer, ultra low-power high performance MEMS motion sensor
High-resolution, high-stability 3-axis digital inclinometer for industrial applications
