サーマル・シャットダウンおよびカレント・リミット機能搭載の高電圧 & レール・ツー・レールのデュアルチャネル・オペアンプ






  • 広範な電源電圧範囲:4V~36V
  • 高出力電流:200mA
  • レール・ツー・レール出力、低レール入力
  • ゲイン帯域幅積:3.1MHz
  • 内部サーマル・シャットダウンおよび出力電流制限機能
  • 高いRFノイズ耐性
  • 動作温度範囲:-40℃~+125℃


サーボ・モータ サーボ・ドライバ
バルブ・ドライバ バルブ・ドライバ
パワー・マネージメント DC電源、ACソース
携帯機器 携帯型機器
モータ制御 モータ制御


br2206autoics pdf




使いやすい製品セレクタとパラメータ検索エンジンにより、スムーズでシンプルなナビゲーション操作を実現。お使いのアプリケーションに適したオペアンプ、コンパレータ、その他のシグナル・コンディショニング・デバイスを迅速にお探しいただけます。Google Play、App Store、Wandoujiaから入手可能です。

Recommended resources

br2206autoics pdf

This brochure presents a large portfolio of ST’s products and solutions dedicated to voltage regulation, DC-DC conversion, signal amplification, current sensing, and LED driving as well as many other small analog ICs that are needed for today’s ever-growing automotive industry. Includes application recommendations and information on additional developer resources.

 Steer by Wire resolver driver with the TSB582 dual op amp

Watch our short video and see how an automotive power op amp can drive a rotary resolver used in traction inverters or steer-by-wire (SbW) systems. The TSB582 is also a great choice for servo motor designs, solenoid drivers, and magnetic sensors including LVDT displacement sensors.

op amps pdf

Download this very practical PDF resource covering:

  • How do I pick the right op amp for an application?
  • Typical op-amp applications and key parameters
  • Step-by-step op-amp selection using the ST Op Amps App
  • ST's op-amp naming convention Glossary
stsw-edsim pdf

Design your analog circuit, get a quick preview with fully annotated schematic and BOM, and then run the electrical simulation through eDSim for fast and accurate simulations and reliable design validation

op amp finder

A user-friendly product selector ensuring a smooth and simple navigation experience with a parametric search engine that lets you rapidly identify the appropriate operational amplifier, comparator, or other signal conditioning device that best fits your application. Available on Google Play, App Store and Wandoujia.

webinar current sensing

Rotary resolvers are the preferred solution for reliable angular position sensing in industrial and automotive applications — harsh environments characterized by high temperature, vibration, humidity, and systems contaminated by dust or oil. Watch our webinar replay, and you will learn about:

  • Rotary resolver architecture and operation
  • Automotive, military, aerospace, and industrial application examples
  • TSB582 to energize the input phase
  • TSB514 to signal condition the output
