STSPIN250

Active
Design Win Education Education

Low voltage brush DC motor driver

Download datasheet Order Direct
Overview
Sample & Buy
Solutions
Documentation
CAD Resources
Tools & Software
Quality & Reliability
Get Started
Partner products
Sales Briefcase

Product overview

Description

The STSPIN250 is a single brush DC motor driver integrating a low Rds(ON) power stage in a small VFQFPN 3 x 3 mm package.

The full-bridge implements a PWM current controller with fixed OFF time.

The device is designed to operate in battery-powered scenarios and can be forced in a zero-consumption state allowing a significant increase in battery life.

The device offers a complete set of protection features including overcurrent, overtemperature and short-circuit protection.

  • All features

    • Operating voltage from 1.8 to 10 V
    • Maximum output current 2.6 Arms with OUTAx paralled to OUTBx
    • RDS(ON) HS + LS = 0.2 Ω typ.
    • Current control with programmable off-time
    • Full protection set
      • Non-dissipative overcurrent protection
      • Short-circuit protection
      • Thermal shutdown
    • Energy saving and long battery life with standby consumption less than 80 nA

You might also like...

All tools & software

    • Part number
      Status
      Description
      Type
      Supplier

      STSPIN250 click

      Active

      Brushed DC motor driver with the current limiting and current sensing

      Evaluation Boards from Partners MikroElektronika
      STSPIN250 click

      Description:

      Brushed DC motor driver with the current limiting and current sensing
    • Part number
      Status
      Description
      Type
      Supplier

      STSW-SPIN002

      Active

      Evaluation software with graphical user interface for STSPIN motor driver ICs

      Motor Control Software Development Tools ST
      STSW-SPIN002

      Description:

      Evaluation software with graphical user interface for STSPIN motor driver ICs
    • Part number
      Status
      Description
      Type
      Supplier

      X-NUCLEO-IHM13A1

      Active

      Low voltage brush DC motor driver expansion board for STM32 Nucleo based on the STSPIN250

      STM32 ODE Move-Actuate HW ST
      X-NUCLEO-IHM13A1

      Description:

      Low voltage brush DC motor driver expansion board for STM32 Nucleo based on the STSPIN250

EDA Symbols, Footprints and 3D Models

STMicroelectronics - STSPIN250

Speed up your design by downloading all the EDA symbols, footprints and 3D models for your application. You have access to a large number of CAD formats to fit with your design toolchain.

Symbols

Symbols

Footprints

Footprints

3D model

3D models

Quality and Reliability

Part Number Marketing Status Package Grade Marketing Lead Time Qty Material Declaration**
STSPIN250
Active
VFQFPN 16 3x3x1.0 Industrial -

STSPIN250

Package:

VFQFPN 16 3x3x1.0

Material Declaration**:

PDF XML

Marketing Status

Active

Package

VFQFPN 16 3x3x1.0

Grade

Industrial

Marketing Lead Time Qty

-

(**) The Material Declaration forms available on st.com may be generic documents based on the most commonly used package within a package family. For this reason, they may not be 100% accurate for a specific device. Please contact our sales support for information on specific devices.

Sample & Buy

Swipe or click the button to explore more details Don't show this again
Part Number
Order from distributors
Order from ST
Marketing Status
ECCN (US)
ECCN (EU)
Packing Type
Package
Temperature (°C) Country of Origin
Budgetary Price (US$)*/Qty
min
max
STSPIN250 Available at distributors

Distributor availability of STSPIN250

Distributor Name
Region Stock Min. Order Third party link

Distributor reported inventory date:

No availability of distributors reported, please contact our sales office
Active
EAR99 NEC Tape and Reel VFQFPN 16 3x3x1.0 -40 150 THAILAND

STSPIN250 Active

Package:
VFQFPN 16 3x3x1.0
ECCN (US):
EAR99
Budgetary Price (US$)*/Qty:
-

Part Number:

STSPIN250

ECCN (EU):

NEC

Packing Type:

Tape and Reel

Operating Temperature (°C)

Min:

-40

Max:

150

Country of Origin:

THAILAND
