ST2100

Active
Design Win

Broadband powerline communication SoC optimized for audio/video streaming and consumer applications

Download datasheet

Product overview

Description

The STreamPlug ST2100 device is the STMicroelectronics® “Broad Band Powerline Communication” (BB PLC) solution, based on the powerful ARM926EJ-S™ processor (up to 333 MHz), widely used in applications where high computation performance is required, such as consumer (“Home Area Network” or HAN), industrial and smart grid applications.

In addition, the STreamPlug ST2100 has a memory management unit (MMU) that allows virtual memory management - making the system compliant with the Linux® operating system. It also offers 16 Kbyte of data cache, 32 Kbyte of instruction cache, JTAG and ETM™ (Embedded Trace Macrocell™ ) for debug operations.

A large set of peripherals allows a wide flexibility of the usage of the system in most of the possible PLC broadband applications (indoor and outdoor).

  • All features

    • Configurable HW engine for multiple HomePlug® PHY and real-time MAC layers processing supporting:
      • HomePlug AV and 1.0 standards
      • HomePlug Green PHY™ standard
    • Integrated analog front-end
    • ARM926EJ-S™ 32-bit RISC CPU up to 333 MHz
    • 8/16 bit DDR mobile at 166 MHz and DDR2 at 333 MHz memory controller
    • Serial memory interface
    • 8/16-bits NOR Flash/NAND Flash and SRAM memories controllers
    • Multichannel DMA controller
    • Ethernet 10/100 MAC with MII interface
    • USB 2.0
    • PCI Express and S-ATA
    • Color LCD (CLCD) controller
    • JPEG codec accelerator
    • Cryptographic coprocessor
    • Up to 40 GPIOs
    • Enhanced I2S (digital audio interface)
    • I2C master/slave mode
    • Master/slave SSI
    • Two independent UARTs
    • Fast IrDA®
    • Real-time clock
    • Configurable serial port (SPORT) interface for external DSP and audio codec (ADC and DAC) in I2S mode
    • Transport stream interface (video TS)
    • Vectored interrupt controller (VIC)
    • JTAG (IEEE1149.1) interface
    • Three CPU instruction sets

You might also like...

EDA Symbols, Footprints and 3D Models

STMicroelectronics - ST2100

Speed up your design by downloading all the EDA symbols, footprints and 3D models for your application. You have access to a large number of CAD formats to fit with your design toolchain.

Please select one model supplier :

Symbols

Symbols

Footprints

Footprints

3D model

3D models

Quality and Reliability

Part Number Marketing Status Package Grade RoHS Compliance Grade Material Declaration**
ST2100
Active
TFBGA 373 12x12x1.0 Industrial Ecopack2
ST2100TR
Active
TFBGA 373 12x12x1.0 Industrial Ecopack2

ST2100

Package:

TFBGA 373 12x12x1.0

Material Declaration**:

PDF XML

Marketing Status

Active

Package

TFBGA 373 12x12x1.0

Grade

Industrial

RoHS Compliance Grade

Ecopack2

ST2100TR

Package:

TFBGA 373 12x12x1.0

Material Declaration**:

PDF XML

Marketing Status

Active

Package

TFBGA 373 12x12x1.0

Grade

Industrial

RoHS Compliance Grade

Ecopack2

(**) The Material Declaration forms available on st.com may be generic documents based on the most commonly used package within a package family. For this reason, they may not be 100% accurate for a specific device. Please contact our sales support for information on specific devices.

Sample & Buy

Swipe or click the button to explore more details Don't show this again
Part Number
Order from distributors
Order from ST
Marketing Status
ECCN (US)
ECCN (EU)
Packing Type
Package
Temperature (°C) Country of Origin
Budgetary Price (US$)*/Qty
min
max
ST2100TR Available at distributors

Distributor availability of ST2100TR

Distributor Name
Region Stock Min. Order Third party link

Distributor reported inventory date:

No availability of distributors reported, please contact our sales office
Active
5A992.c 5A002.a.2 Tape and Reel TFBGA 373 12x12x1.0 - - CHINA
ST2100 Available at distributors

Distributor availability of ST2100

Distributor Name
Region Stock Min. Order Third party link

Distributor reported inventory date:

No availability of distributors reported, please contact our sales office
Active
5A992.c 5A002.a.2 Tray TFBGA 373 12x12x1.0 - - CHINA

ST2100TR Active

Package:
TFBGA 373 12x12x1.0
ECCN (US):
5A992.c
Budgetary Price (US$)*/Qty:
-

Part Number:

ST2100TR

ECCN (EU):

5A002.a.2

Packing Type:

Tape and Reel

Operating Temperature (°C)

Min:

-

Max:

-

Country of Origin:

CHINA

ST2100 Active

Package:
TFBGA 373 12x12x1.0
ECCN (US):
5A992.c
Budgetary Price (US$)*/Qty:
-

Part Number:

ST2100

ECCN (EU):

5A002.a.2

Packing Type:

Tray

Operating Temperature (°C)

Min:

-

Max:

-

Country of Origin:

CHINA
