High-voltage, rail-to-rail, dual-channel operational amplifier with thermal shutdown and output current limiter


The TSB582 is a high performance dual operational amplifier featuring high supply voltages and high output current capability while being protected through internal current limiting and thermal shutdown.

The TSB582 is a unity gain stable, dual operational amplifier with high current capability, featuring internal protections against overtemperature and current overload conditions for both industrial and automotive applications.

In addition, the TSB582 has enhanced ESD and RF noise immunity. It typically outputs up to 200 mA per channel to drive low resistance inductive loads such as angle resolvers, lineout cables and piezo actuators.

Key features

  • Wide supply voltage: 4 to 36 V
  • High output current 200 mA
  • Rail-to-rail output, low rail input
  • Gain bandwidth product: 3.1 MHz
  • Internal thermal shutdown & output current limiter
  • Enhanced RF noise immunity
  • Extended temperature range: -40 to 125 °C
  • Automotive grade application

10 year longevity  st op amps logo automotive

Application examples

servo motor Servo drivers
valve drivers Valve drivers
power-management DC power supplies, AC source
portable devices Portable instrumentation
motor control Motor control

Recommended resources

br2206autoics pdf

This brochure presents a large portfolio of ST’s products and solutions dedicated to voltage regulation, DC-DC conversion, signal amplification, current sensing, and LED driving as well as many other small analog ICs that are needed for today’s ever-growing automotive industry. Includes application recommendations and information on additional developer resources.

 Steer by Wire resolver driver with the TSB582 dual op amp

Watch our short video and see how an automotive power op amp can drive a rotary resolver used in traction inverters or steer-by-wire (SbW) systems. The TSB582 is also a great choice for servo motor designs, solenoid drivers, and magnetic sensors including LVDT displacement sensors.

op amps pdf

Download this very practical PDF resource covering:

  • How do I pick the right op amp for an application?
  • Typical op-amp applications and key parameters
  • Step-by-step op-amp selection using the ST Op Amps App
  • ST's op-amp naming convention Glossary
stsw-edsim pdf

Design your analog circuit, get a quick preview with fully annotated schematic and BOM, and then run the electrical simulation through eDSim for fast and accurate simulations and reliable design validation

op amp finder

A user-friendly product selector ensuring a smooth and simple navigation experience with a parametric search engine that lets you rapidly identify the appropriate operational amplifier, comparator, or other signal conditioning device that best fits your application. Available on Google Play, App Store and Wandoujia.


The TSB582 is ST’s first high-voltage and high-current dual-operational amplifier with one of the smallest packages in the industry (SO8 with exposed pad and DFN8 with wettable flanks and exposed pad).

webinar current sensing

Rotary resolvers are the preferred solution for reliable angular position sensing in industrial and automotive applications — harsh environments characterized by high temperature, vibration, humidity, and systems contaminated by dust or oil. Watch our webinar replay, and you will learn about:

  • Rotary resolver architecture and operation
  • Automotive, military, aerospace, and industrial application examples
  • TSB582 to energize the input phase
  • TSB514 to signal condition the output
