Description

The X-CUBE-DISPLAY STM32Cube Expansion Package runs on the STM32 microcontroller. It offers a complete project example enabling easy and simple use of the STM32 display expansion boards for STM32 Nucleo boards. It includes an STM32CubeMX configuration project, as well embedded software extending Nucleo boards with graphic user interface capability, including display, joystick control and external memory management.

Additionally, demonstration binaries are provided as joint resources while more advanced examples are available with the TouchGFX Designer tool, part of the X-CUBE-TOUCHGFX Expansion Package.

All features
Software building block suppporting the addition of display expansion boards to Nucleo-64 and Nucleo-144 boards

Simple “hello world” example available onthe X-NUCLEO-GFX01M1 expansion board connected to the NUCLEO-G071RB or NUCLEO-L476RG Nucleo-64 development boardthe X-NUCLEO-GFX01M2 expansion board connected to the NUCLEO-G071RB or NUCLEO-WB55RG Nucleo-64 development boardthe X-NUCLEO-GFX02Z1 expansion board connected to the NUCLEO-L4R5ZI or NUCLEO-U575ZI Nucleo-144 development board

Easy portability across STM32 microcontrollers with STM32CubeMX in the STM32Cube ecosystem

Free and user-friendly license terms
Read more Read less
