32F469IDISCOVERY

Discovery kit with STM32F469NI MCU

Quick View Resources

The STM32F469 Discovery kit (32F469IDISCOVERY) allows users to easily develop applications with the STM32F469 high-performance MCUs with ARM^®Cortex^®-M4 core and Chrom-ART Accelerator^™. The discovery kit enables a wide range of use cases taking advantage of premium graphics, audio, multi-sensor support, WVGA color display, security, memory extension and connectivity features. An embedded ST-LINK/V2-1 debugger/programmer is included; specialized add-on boards can be connected thanks to the Arduino^™UNO or to the expansion connectors.

Key Features

STM32F469NIH6 microcontroller featuring 2 Mbytes of Flash memory and 324 Kbytes of RAM in BGA216 package
On-board ST-LINK/V2-1 SWD debugger, supporting USB reenumeration capability:
- Mbed-enabled (mbed.org)
- USB functions: USB virtual COM port, mass storage, debug port
4 inches 800x480 pixel TFT color LCD with MIPI DSI interface and capacitive touch screen
SAI Audio DAC, with a stereo headphone output jack
3 MEMS microphones
MicroSD card connector
I2C extension connector
4Mx32bit SDRAM
128-Mbit Quad-SPI NOR Flash
Reset and wake-up buttons
4 color user LEDs
USB OTG FS with Micro-AB connector
Three power supply options:
Expansion connectors and Arduino^™UNO V3 connectors
Comprehensive free software including a variety of examples, part of STM32Cube package
Supported by a wide choice of integrated development environments


Resources

Technical Documentation

Product Specifications

	Description	Version	Size
	DB2650: Discovery kit with STM32F469NI MCU	1.0	261 KB

Technical Notes & Articles

	Description	Version	Size
	TN1235: Overview of ST-LINK derivatives	2.0	670 KB

User Manuals

Description	Version	Size
UM1932: Discovery kit with STM32F469NI MCU	2.0	1 MB
UM2052: Getting started with STM32 MCU Discovery Kits software development tools	1.0	1 MB
UM1962: Getting started with STM32F469I discovery software development tools	1.0	1 MB

Presentations & Training Material

Presentations

	Description	Version	Size
	STM32 Development Boards Portfolio	1.0	3 MB

Hardware Resources

Board Manufacturing Specifications

	Description	Version	Size
	STM32F469I-DISCO Gerber files	1.0.0	1 MB

Bill of Materials

	Description	Version	Size
	STM32F469I-DISCO BOM	1.0.0	36 KB

Schematic Pack

	Description	Version	Size
	STM32F469I-DISCO schematics	1.0.0	3 MB

Publications and Collaterals

Flyers

	Description	Version	Size
	STM32 for makers - Releasing your creativity	18.01	1 MB
	STM32F469/479 World’s first MIPI-DSI MCU	17.07	581 KB

Brochures

	Description	Version	Size
	STM32 32-bit MCU family - Leading supplier of Arm® Cortex®-M microcontrollers	18.02	2 MB

Legal

License Agreement

	Description	Version	Size
	Evaluation products license agreement	1.6	74 KB
	Open Reference Material License Agreement v5		42 KB

Tools and Software

Development Tools

Software Development Tools

Part Number	Manufacturer	Description
ST-LINK-SERVER	ST	ST-LINK server software module
STSW-LINK007	ST	ST-LINK, ST-LINK/V2, ST-LINK/V2-1 firmware upgrade
STSW-LINK009	ST	ST-LINK, ST-LINK/V2, ST-LINK/V2-1 USB driver signed for Windows7, Windows8, Windows10

Embedded Software

MCUs Embedded Software

Part Number	Manufacturer	Description
DRA-TouchGFX	Draupner Graphics	TouchGFX graphics framework for STM32
STM32CubeF4	ST	STM32Cube MCU Package for STM32F4 series (HAL, Low-Layer APIs and CMSIS (CORE, DSP, RTOS), USB, TCP/IP, File system, RTOS, Graphic - coming with examples running on ST boards: STM32 Nucleo, Discovery kits and Evaluation boards)
TARA-Embd-Wizard	TARA System	Embedded Wizard graphic framework for STM32

Related Applications

Featured Videos

See All

Sample & Buy

Part Number	Marketing Status	Unit Price (US$) *	Quantity	Specific features	ECCN (US)	Country of Origin	More info	Order from ST	Order from Distributors
STM32F469I-DISCO	Active : Product is in volume production	59.0	1	-	3A991A2	-	MORE INFO	Buy Direct Add to cart	DISTRIBUTOR AVAILABILITY

(*) Suggested Resale Price per unit (USD) for BUDGETARY USE ONLY. For quotes, prices in local currency, please contact your local ST Sales Office or our Distributors

Quality & Reliability

Part Number	Marketing Status	RoHS Compliance Grade	WEEE Compliant	Material Declaration**
STM32F469I-DISCO	Active	Ecopack1	-

(**) The Material Declaration forms available on st.com may be generic documents based on the most commonly used package within a package family. For this reason, they may not be 100% accurate for a specific device. Please contact our sales support for information on specific devices.
