Product overview
Key Benefits
Space-saving, low power industrial solution
Compact DFN10 3x3 mm package, low quiescent current and −40°C to +125°C operation enable energy‑efficient designs in harsh environments
Enhanced protection and reliability
Integrated fail‑safe receiver, hot‑swap capability and up to ±16 kV IEC 61000‑4‑2 contact ESD protection maximize system robustness and uptime
Robust high-speed RS-485 communication
Up to 50 Mbps, full‑duplex operation and high receiver hysteresis ensure reliable data integrity in noisy industrial networks
Description
The ST4E1650F is a low-power differential line transceiver for data transmission standard RS485 applications in full-duplex mode.
The ST4E1650F operates up to 50 Mbps. It is ideal for multi-point applications in a constrained and difficult industrial environment. It is robust to ESD transients. In particular, the bus pins support ±16 kV IEC 61000-4-2 contact discharge. It features robust hot-swap capability during switching on and off, or during plug-in. The fail-safe receiver ensures a logic-high output when the inputs are shorted, open, or indeterminate. The high level of receiver hysteresis improves the noise rejection and the signal integrity.
The ST4E1650F is available in a small 3 mm x 3 mm DFN10 package and operates in a -40 °C to 125 °C temperature range.
-
All features
- Meets or exceeds the requirements of the TIA/EIA-485A standard
- 3 V to 3.6 V supply voltage
- High speed: up to 50 Mbps data rate
- Up to 128 bus nodes
- Receiver hysteresis of 70 mV
- Full-duplex topology
- Integrated protections
- Fail-safe receiver (bus open, idle, and shorted)
- Thermal shutdown protection
- Hot swap capability
- Bus I/O ESD protection
±16 kV IEC61000-4-2 contact discharge ±30 kV HBM ±4 kV IEC61000-4-4 fast transient burst
- Low quiescent current in shutdown mode
- -40 °C to +125 °C operating temperature
- Available in DFN10 industry standard
EDA Symbols, Footprints and 3D Models
STMicroelectronics - ST4E1650F
Speed up your design by downloading all the EDA symbols, footprints and 3D models for your application. You have access to a large number of CAD formats to fit with your design toolchain.
Please select one model supplier :
Symbols
Footprints
3D models
Quality and Reliability
| Part Number | Marketing Status | Package | Grade | RoHS Compliance Grade | Longevity Commitment | Longevity Starting Date | Material Declaration** |
|---|---|---|---|---|---|---|---|
| ST4E1650FIQT | Preview | VDFPN 10 3x3x1.0 | Industrial | Ecopack3 | 10 | 2023-05-23T00:00:00.000+02:00 | |
ST4E1650FIQT
Package:
VDFPN 10 3x3x1.0Material Declaration**:
(**) The Material Declaration forms available on st.com may be generic documents based on the most commonly used package within a package family. For this reason, they may not be 100% accurate for a specific device. Please contact our sales support for information on specific devices.
