ITAP 2024

Based on 2nd generation STM32MP2 microprocessor which embeds secured and enhanced peripherals for connected applications. Based on Arm Cortex-A35 core, STM32MP2 MPUs offer advanced Edge AI capabilities with 1.35 TOPS AI accelerator. ST provides free of charge X-Linux-AI open-source software ecosystem to support multiple different Edge AI use cases in Industrial Automation and IoT segments.

This showstopper showcases the most comprehensive motor control demo we’ve ever put together. This solution comprises 8 motor control modules, which use 4 different reference designs with loads ranging from 500 W to 22 kW. Each of the motors controls a rope that pulls a load and demonstrates precision position control, in a harmonic movement coordinated simultaneously with the others. Each motor drive executes the commands sent by I/O link from the podium where an HMI interface allows to select the mode, and each of them collects temperature and vibration data, execute condition monitoring algorithms and sends data to Baidu cloud wirelessly, which then informs back the system and its HMI to reflect how the systems behave and save power, among other things.

The EVSPIN32G4-DUAL is a demonstration board based on the STSPIN32G4 and STDRIVE101 for applications using two three-phase brushless motors. The STSPIN32G4 is a system in package integrating in a 9x9 mm VFQFPN package, a triple high-performance half-bridge gate driver with a rich set of programmable features and one mixed signal STM32G431 microcontroller. The STDRIVE101 is a triple half-bridge gate driver in a compact 4x4 VFQPN package featuring 600 mA current capability and embedded protections.
