STEVAL-IDB013V1

Active
Design Win

Evaluation platform based on BlueNRG-LPS system-on-chip

Download databrief Order Direct

Product overview

Description

The STEVAL-IDB013V1 evaluation platform is designed to help the user develop and test Bluetooth® Low Energy applications. It uses the low-power BlueNRG-LPS system-on-chip in combination with inertial and environmental MEMS sensors and digital MEMS microphone, and various interface buttons and LEDs.

The BlueNRG-LPS features a 64 MHz, 32-bit Arm Cortex®-M0+ core, 192 KB programmable flash memory, 24 KB SRAM, MPU, and an extensive peripheral set (6x PWM, I²C, SPI/I2S, USART, LPUART, 12-bit ADC SAR).

The BlueNRG-LPS is compliant with the Bluetooth® Low Energy specification, supporting: master, slave, simultaneous master-and-slave roles, data length extension, 2 Mbps, long range, extended advertising and scanning, channel selection algorithm #2, GATT caching, LE Ping procedure, LE power control and path loss monitoring, direction finding (angle of arrival/angle of departure) features.

Serial communication with a PC and three power options (USB only, battery only, external power supply) allow complex application development and testing flexibility.

  • All features

    • Bluetooth® Low Energy evaluation board based on the BlueNRG-LPS (BlueNRG-332VC)
    • Bluetooth® Low Energy 5.2 certified SoC in WLCSP36 package:
      • Master, slave, and simultaneous master-and-slave roles
      • Long range, 2 Mbps data rate, advertising extensions, periodic advertising, CSA#2, GATT caching, LE ping procedure, periodic advertising and periodic advertising sync transfer, LE L2CAP connection-oriented channel, LE power control, and path loss monitoring
      • Supports direction finding with angle of arrival (AoA) and angle of departure (AoD)
    • Uncompromised low-power radio performances:
      • Up to +7 dBm programmable output power (at antenna connector)
      • Excellent receiver sensitivity (-95 dBm @ 1 Mbps, -101 dBm @ 125 kbps - long range)
      • Very low power consumption: 3.4 mA Rx @ sensitivity level, and 4.3 mA Tx @ +0 dBm
    • Integrated 32-bit core Arm Cortex®-M0+, 64 MHz 192-Kbyte flash memory, 24-Kbyte SRAM, MPU, extensive peripheral set
    • Chip antenna, IPD, UFL connector for measuring equipment and Arduino R3 connectors
    • Three power options: USB cable, battery, and external power supply
    • Associated BlueNRG-LPS development kit software package (STSW-BNRGLP-DK) including firmware and documentation
    • 3 user LEDs and 2 user buttons
    • MEMS digital accelerometer/gyroscope
    • MEMS digital pressure/temperature sensor
    • Embedded CMSIS-DAP debugger and drag&drop programming support
    • RoHS compliant

You might also like...

Quality and Reliability

Part Number Marketing Status Package Grade RoHS Compliance Grade WEEE Compliant Material Declaration**
STEVAL-IDB013V1
Active
CARD Industrial Ecopack2 Yes

STEVAL-IDB013V1

Package:

CARD

Material Declaration**:

Marketing Status

Active

Package

CARD

Grade

Industrial

RoHS Compliance Grade

Ecopack2

(**) The Material Declaration forms available on st.com may be generic documents based on the most commonly used package within a package family. For this reason, they may not be 100% accurate for a specific device. Please contact our sales support for information on specific devices.
