The ST pulse width modulation (PWM) controller portfolio covers isolated and non-isolated AC-DC and DC-DC switch mode power supplies with the most common converter topologies, including flyback, forward, and quasi-resonant. ST PWM controllers combine integrated protections and optimized light-load behavior to improve converter efficiency, reduce external component count, and lower overall system cost in demanding industrial and consumer applications. The portfolio also includes widely used UC (current-mode) and SG (voltage-mode) PWM controllers for mainstream SMPS designs, giving designers the flexibility to choose from classic architectures to more advanced control strategies.

The ST pulse width modulation (PWM) controller portfolio covers isolated and non-isolated AC-DC and DC-DC switch mode power supplies with the most common converter topologies, including flyback, forward, and quasi-resonant. ST PWM controllers combine integrated protections and optimized light-load behavior to improve converter efficiency, reduce external component count, and lower overall system cost in demanding industrial and consumer applications. The portfolio also includes widely used UC (current-mode) and SG (voltage-mode) PWM controllers for mainstream SMPS designs, giving designers the flexibility to choose from classic architectures to more advanced control strategies.

Applications

ST PWM controllers support efficient, protected, and optimized AC-DC and DC-DC power conversion across a wide range of load conditions.

Smart chargers and adapters
Smart chargers and adapters
Isolated auxiliary power supply 20-75W
Isolated auxiliary power supply 20-75W
Isolated auxiliary power supply up to 20W
Isolated auxiliary power supply up to 20W
LED / OLED TV
LED / OLED TV
Lighting
Lighting

Product types

Current mode PWM controllers
Controllers optimized for current-mode regulation in a wide range of SMPS designs.
Discover products
Voltage mode PWM controllers
Classic voltage-mode controllers for mainstream and cost-sensitive power-supply architectures.
Discover products
Quasi-resonant and flyback controllers
Controllers designed for high-efficiency flyback topologies and improved light-load operation.
Discover products

Benefits

ST PWM controllers help designers build efficient, robust, and cost-effective power supplies for a wide range of AC-DC and DC-DC applications.

  • Support for a broad range of SMPS topologies
  • Improved converter efficiency across load conditions
  • Optimized light-load and start-up behavior
  • Integrated protections for enhanced robustness
  • Reduced external component count to help lower system cost
  • Flexible options for mainstream and advanced designs
  • Suitable for isolated and non-isolated power conversion
  • Proven control architectures for industrial applications

Featured Products

STACF01A and STACF01B

The STACF01A and STACF01B ICs drive and control active clamp flyback converters with non-complementary driving of the active clamp (high-side, HS) switch.

Compact quasi-resonant PWM controller for ultra-low standby power supplies

The STCH03 features a built-in high-voltage start-up circuit with zero power consumption, fully integrated blocks for primary-side constant-current output regulation and advanced power management, making it the best choice for high efficiency and ultra-low standby consumption power supplies with excellent dynamic performance.

Designed to provide a constant output current (CC) regulation using primary-sensing feedback, the STCH03 reduces BOM costs and simplifies your design as a dedicated current reference IC and current sensor are no longer required.

Moreover, an embedded frequency jitter technique helps reduce EMI noise.
