Rail-to-rail high-speed comparator

Download datasheet

Sample and Buy from our eStore

Sample & Buy
Overview
Tools & Software
Resources
Solutions
Quality & Reliability
Sales Briefcase
eDesignSuite
Get Started
Sample & Buy
Partner products
  • The TS3011 single comparator features a high-speed response time with rail-to-rail inputs. Specified for a supply voltage of 2.2 to 5 V, this comparator can operate over a wide temperature range from -40 °C to 125 °C.

    The TS3011 offers micropower consumption as low as a few hundred microamperes, thus providing an excellent ratio of power consumption current versus response time.
    The TS3011 includes push-pull outputs and is available in tiny packages to overcome space constraints.

    Key Features

    • Propagation delay: 8 ns
    • Low current consumption: 470 μA typ. at 5 V
    • Rail-to-rail inputs
    • Push-pull outputs
    • Supply operation from 2.2 to 5 V
    • Wide temperature range: -40 °C to 125 °C
    • ESD tolerance: 2 kV HBM/200 V MM
    • Latch-up immunity: 200 mA
    • SMD packages
    • Automotive qualification
