STM32L151QD

Active
Education

Ultra-low-power ARM Cortex-M3 MCU with 384 Kbytes Flash, 32 MHz CPU, USB, 3xOp-amp

Download datasheet

Order from our eStore and our distributors

Buy now
Overview
Tools & Software
Resources
Solutions
Quality & Reliability
Sales Briefcase
eDesignSuite
Get Started
Sample & Buy
Partner products
  • The ultra-low-power STM32L151xD and STM32L152xD devices incorporate the connectivity power of the universal serial bus (USB) with the high-performance Arm® Cortex®-M3 32-bit RISC core operating at a frequency of 32 MHz (33.3 DMIPS), a memory protection unit (MPU), high-speed embedded memories (Flash memory up to 384 Kbytes and RAM up to 48 Kbytes), a flexible static memory controller (FSMC) interface (for devices with packages of 100 pins and more) and an extensive range of enhanced I/Os and peripherals connected to two APB buses.

    The STM32L151xD and STM32L152xD devices offer three operational amplifiers, one 12-bit ADC, two DACs, two ultra-low-power comparators, one general-purpose 32-bit timer, six general-purpose 16-bit timers and two basic timers, which can be used as time bases.
    Moreover, the STM32L151xD and STM32L152xD devices contain standard and advanced communication interfaces: up to two I2Cs, three SPIs, two I2S, one SDIO, three USARTs, two UARTs, and an USB. The STM32L151xD and STM32L152xD devices offer up to 34 capacitive sensing channels to simply add a touch sensing functionality to any application.
    They also include a real-time clock and a set of backup registers that remain powered in Standby mode.
    Finally, the integrated LCD controller (except STM32L151xD devices) has a built-in LCD voltage generator that allows to drive up to 8 multiplexed LCDs with the contrast independent of the supply voltage.
    The ultra-low-power STM32L151xD and STM32L152xD devices operate from a 1.8 to 3.6 V power supply (down to 1.65 V at power down) with BOR and from a 1.65 to 3.6 V power supply without BOR option. They are available in the -40 to +85 °C and -40 to +105 °C temperature ranges. A comprehensive set of power-saving modes allows the design of low-power applications.

    Key Features

    • Ultra-low-power platform
      • 1.65 V to 3.6 V power supply
      • -40°C to 105°C temperature range
      • 305 nA Standby mode (3 wakeup pins)
      • 1.15 μA Standby mode + RTC
      • 0.475 μA Stop mode (16 wakeup lines)
      • 1.35 μA Stop mode + RTC
      • 11 μA Low-power run mode
      • 230 μA/MHz Run mode
      • 10 nA ultra-low I/O leakage
      • 8 μs wakeup time
    • Core: Arm® Cortex®-M3 32-bit CPU
      • From 32 kHz up to 32 MHz max
      • 33.3 DMIPS peak (Dhrystone 2.1)
      • Memory protection unit
    • Up to 34 capacitive sensing channels
    • CRC calculation unit, 96-bit unique ID
    • Reset and supply management
      • Low-power, ultrasafe BOR (brownout reset) with 5 selectable thresholds
      • Ultra-low-power POR/PDR
      • Programmable voltage detector (PVD)
    • Clock sources
      • 1 to 24 MHz crystal oscillator
      • 32 kHz oscillator for RTC with calibration
      • High Speed Internal 16 MHz factory-trimmed RC (+/- 1%)
      • Internal low-power 37 kHz RC
      • Internal multispeed low-power 65 kHz to 4.2 MHz
      • PLL for CPU clock and USB (48 MHz)
    • Pre-programmed bootloader
      • USB and USART supported
    • Serial wire debug, JTAG and trace
    • Up to 116 fast I/Os (102 I/Os 5V tolerant), all mappable on 16 external interrupt vectors
    • Memories
      • 384 Kbytes of Flash memory with ECC (with 2 banks of 192 Kbytes enabling Rww capability)
      • 48 Kbytes of RAM
      • 12 Kbytes of true EEPROM with ECC
      • 128-byte backup register
      • Memory interface controller supporting SRAM, PSRAM and NOR Flash
    • LCD driver (except STM32L151xD devices) up to 8x40 segments, contrast adjustment, blinking mode, step-up converter
    • Rich analog peripherals (down to 1.8V)
      • 3x operational amplifiers
      • 12-bit ADC 1 Msps up to 40 channels
      • 12-bit DAC 2 ch with output buffers
      • 2x ultra-low-power-comparators(window mode and wakeup capability)
    • DMA controller 12x channels
    • 12x peripheral communication interfaces
      • 1x USB 2.0 (internal 48 MHz PLL)
      • 5x USARTs
      • Up to 8x SPIs (2x I2S, 3x 16 Mbit/s)
      • 2x I2Cs (SMBus/PMBus)
      • 1x SDIO interface
    • 11x timers: 1x 32-bit, 6x 16-bit with up to 4 IC/OC/PWM channels, 2x 16-bit basic timers, 2x watchdog timers (independent and window)

Circuit Diagram

Sample & Buy

Part Number
Package
Packing Type
Temperature (°C) Marketing Status
Budgetary Price (US$)*
Quantity
ECCN (US)
More info
Order from Distributors
Order from ST
min
max
STM32L151QDH6 UFBGA 7X7X0.6 132L P 0.5 R 12X12 Tray -40 85
Active
3.8202 10000 3A991A2
MORE INFO

Country of Origin:

PHILIPPINES

Check Availability

Distributor availability ofSTM32L151QDH6

Distributor Name
Region Stock Min. Order Third party link
DIGIKEY WORLDWIDE 78 1 Order Now
MOUSER WORLDWIDE 300 1 Order Now
Farnell Element14 EUROPE 552 1 Order Now

Distributor reported inventory date: 2019-12-12

Distributor Name

DIGIKEY

Stock

78

Min.Order

1

Region

WORLDWIDE Order Now

MOUSER

Stock

300

Min.Order

1

Region

WORLDWIDE Order Now

Farnell Element14

Stock

552

Min.Order

1

Region

EUROPE Order Now

Distributor reported inventory date: 2019-12-12

Buy now
STM32L151QDH6TR UFBGA 7X7X0.6 132L P 0.5 R 12X12 Tape And Reel -40 85
Active
3.8202 10000 3A991A2
MORE INFO

Country of Origin:

PHILIPPINES

Check Availability

Distributor availability ofSTM32L151QDH6TR

Distributor Name
Region Stock Min. Order Third party link
ARROW EUROPE 2500 0 Order Now

Distributor reported inventory date: 2019-12-12

Distributor Name

ARROW

Stock

2500

Min.Order

0

Region

EUROPE Order Now

Distributor reported inventory date: 2019-12-12

STM32L151QDH6

Package

UFBGA 7X7X0.6 132L P 0.5 R 12X12

Packing Type

Tray

Unit Price (US$)

3.8202*

Distributor availability ofSTM32L151QDH6

Distributor Name
Region Stock Min. Order Third party link
DIGIKEY WORLDWIDE 78 1 Order Now
MOUSER WORLDWIDE 300 1 Order Now
Farnell Element14 EUROPE 552 1 Order Now

Distributor reported inventory date: 2019-12-12

Distributor Name

DIGIKEY

Stock

78

Min.Order

1

Region

WORLDWIDE Order Now

MOUSER

Stock

300

Min.Order

1

Region

WORLDWIDE Order Now

Farnell Element14

Stock

552

Min.Order

1

Region

EUROPE Order Now

Distributor reported inventory date: 2019-12-12

Operating Temperature (°C)

(min)

-40

(max)

85

Marketing Status

Active

Unit Price (US$)

3.8202

Quantity

10000

ECCN (US)

3A991A2

Country of Origin

PHILIPPINES

STM32L151QDH6TR

Package

UFBGA 7X7X0.6 132L P 0.5 R 12X12

Packing Type

Tape And Reel

Unit Price (US$)

3.8202*

Distributor availability ofSTM32L151QDH6TR

Distributor Name
Region Stock Min. Order Third party link
ARROW EUROPE 2500 0 Order Now

Distributor reported inventory date: 2019-12-12

Distributor Name

ARROW

Stock

2500

Min.Order

0

Region

EUROPE Order Now

Distributor reported inventory date: 2019-12-12

Operating Temperature (°C)

(min)

-40

(max)

85

Marketing Status

Active

Unit Price (US$)

3.8202

Quantity

10000

ECCN (US)

3A991A2

Country of Origin

PHILIPPINES

(*) Suggested Resale Price per unit (USD) for BUDGETARY USE ONLY. For quotes, prices in local currency, please contact your local ST Sales Office  or our Distributors
