Electric car charging station with a blue car plugged in, set against a backdrop of solar panels and wind turbines.

The STPOWER family features advanced power technologies designed to meet the demands of both high- and low-voltage applications. These solutions are offered in a versatile range of discrete and module packages, as well as innovative die-bonding technologies.

With integrated protection features, STPOWER products enable designers to develop high-efficiency, customized applications with extended lifespans.

Electric car charging station with a blue car plugged in, set against a backdrop of solar panels and wind turbines.

STPOWER delivers performance, durability, and reliability for industrial, automotive, and consumer applications.

ST supports customer design investments by guaranteeing the availability of selected devices for at least 10 or 7 years.

The majority of STPOWER SiC MOSFETs, low- and high-voltage silicon MOSFETs, IGBTs, and intelligent power modules (IPMs) are certified as part of ST’s 10-year longevity program.

Product types

Circuit symbols of an IGBT
IGBTs
Breakdown voltages from 300 to 1700 V. Low VCE(SAT) for reduced conduction losses. Improved switch-off energy spread versus increasing temperature.
Find products
Circuit symbols of a power bipolar
Power bipolar
A wide range that includes Darlington transistors and BJTs with a VCES from 15 to 1700 V.
Find products
Circuit symbols of a silicon power MOSFET
Power MOSFETs
Broad range of breakdown voltages from -100 to 1700 V, with low gate charge and low on-resistance, combined with state-of-the-art packaging.
Find products
Circuit symbols of a GAN transistor
GaN transistors
GaN technolopgy excels in high-frequency applications, offering superior efficiency, high power density, and extremely fast switching.
Find products
Circuit symbols of a silicon carbide MOSFET
SiC MOSFETs
From 650 to 2200 V, SiC MOSFETs enhance power efficiency, enable more compact and lighter systems, and are ideal for high-voltage, high-performance applications.
Find products

Featured Products

Automotive MOSFETs in tiny 5x6 mm dual-side cooling package

Improved thermal characteristics

1200 V IGBT S series

Industry’s lowest saturation voltage
