High-side switch controller with intelligent fuse protection for automotive applications


Automotive high-side switch controller combines enhanced system-protection and diagnostic features with ST’s I2-t silicon-fuse feature

Its flexibility is ideal for the latest automotive zonal electronic/electrical (E/E) architectures that boost efficiency and reliability while supporting increased electrification and extra functions for smart driving.

Key features

The feature-rich and adaptable VNF1048F has a serial peripheral interface (SPI) for a host microcontroller to configure and monitor system-protection and diagnostic features. These include under-voltage and over-temperature protection, thermal protection for the external high-side MOSFET, desaturation shutdown, and I2-t fuse settings. High-precision digital current sensing is built in. Analog-to-digital converters (ADCs) for monitoring the temperature-sensing thermistor voltage, output voltage, and MOSFET drain-source voltage are also integrated.

Application examples

automotive 12 V, 24 V and 48 V automotive applications
automotive power distribution Automotive Power distribution

Recommended resources

ev vnf1048f

The EV-VNF1048F board provides an easy way to connect a VNF1048F controller into an existing system to create an intelligent high side switch for 12 V, 24 V and 48 V automotive applications.

stsw ev vnf1048f

Designed to configure and control the VNF1048F high-side switch controller in its evaluation board, the GUI provides complete access to device features with a complete set of diagnostics for easy debugging.

sti2fuse automotive switches

Smart switch controllers for automotive power applications help extend EV range and reduce vehicle carbon footprint

video video: sti<sup>2</sup>fuse – driving to a greener future

Helping car designers manage more computing power and data/power distribution while optimizing weight and cost, as well as energy management, discover this new approach to fuse management in modern cars.

efuse pdf whitepaper

This whitepaper looks at a new approach to circuit protection and switching in automotive architectures. With decades of automotive electronics knowledge and expertise, ST has developed a new family of intelligent electronic fuses, STi2Fuse, designed to assist OEMs in the journey ahead.
